Removing the topcase
10
OA
with topcase
116
Turn the key in topcase lock 1
z
to the OPEN position.
Push the topcase lock forward.
Topcase handle 2 pops up.
Turn the key to the RELEASE
position in the topcase lock.
Pull release lever 4 to the rear
and at the same time lift the
topcase slightly by means of
the carry handle.
Work the topcase to the rear
to remove it from the topcase
carrier.
Installing topcase
OA
with topcase
Make sure that topcase
handle 2 is extended and that
the key in the topcase lock is
in the RELEASE position.
Seat the topcase in the top-
case carrier at the front.
Pull release lever 4 back; at the
same time seat the rear of the
topcase in the topcase carrier.
Close topcase handle 2.
If applicable, turn the key in the
topcase lock to the CLOSE
position and remove the key
from the lock.
