Threaded fasteners
Front wheel
Clamping screws (quick-release
axle) in telescopic forks
M6 x 30
Brake caliper to fork leg
M8 x 32 - 10.9
Rear wheel
Rear wheel to output shaft
M10 x 1.25 x 40
Value
Tighten screws six times in alternate
sequence
8 Nm
28 Nm
Value
tighten in diagonally opposite sequence
60 Nm
12
Valid
125
Valid
z
