Indicator and warning
3
lights
20
1
Turn indicators, left
(
46)
2
General warning light
(
26)
3
High-beam headlight
(
43)
4
Daytime riding light
(
43)
5
Reserve (flashes yellow
during charging and
shows green when high-
voltage battery unit is fully
charged)
z
6
DWA (
48)
Photosensor (
7
Insulation fault (shows yel-
low) (
31)
High-voltage safety
connector not connected
(shows red) (
8
RBS (
32)
TCA (
32)
9
ABS (
32)
50)
31)
