Maintenance And Storage - MSA Workman User Instructions

P/N 10112828
(3) Consideration MUST be given to the necessary minimum clearance below the user to prevent a collision with the structure or the ground. The amount of clearance
needed depends upon the type of connecting subsystem used, and the location of the anchorage or anchorage connector. Prevent swing falls and impact with objects
in or adjacent to the fall path. Work directly under the anchorage/anchorage connector at all times. Failure to follow this warning can result in serious injury or death.
(4) Clearance between the position of the Tripod feet when erected and in working position and the access through which the worker will be lowered shall be such that
none of the Tripod legs will be positioned above the access or be placed too close to the edge of a hole and be allowed to fall into the opening. Clearance between the
working position of each of the Tripod feet and the outside of the anchorage shall be a minimum of 0.9 m and shall allow unrestricted movement of support personnel
above during erection, use and compaction (FIGS 11-12). Keep work area free from obstructions, trip hazards and spills which could impair the safe operation of the
Fall-Rescue Work System.
(5) There must be sufficient exterior clearance above the anchorage to fully erect the Tripod. This clearance is given in figure 1. Interior headroom depends upon the
system components (optional accessories) that may be attached to the Tripod head. Refer to the User Instructions supplied with each system component to determine
the effect on overhead clearance due to such installation.
(6) Acidic, alkaline, or other environments with harsh substances may damage the hardware elements of this Tripod. If working in a chemically aggressive environment,
consult MSA to determine acceptable system components for your specific conditions. Chemical hazards, heat and corrosion may damage the Tripod. More frequent
formal inspections are required in environments with chemical hazards, heat and corrosion. Do not use in environments with temperatures greater than 85 °C. Do
not expose to corrosive environments for prolonged periods. Use extreme caution when working near energized electrical sources. Maintain a safe working distance
(preferably at least 3 m) from electrical hazards. When working near moving machinery parts (e.g. conveyors, rotating shafts, presses, etc.), make sure that there are
no loose elements in any part of the system.
(7) The user must have a rescue plan and the means at hand to implement it; and that plan must take into account the equipment and special training necessary to
effect prompt rescue under all foreseeable conditions.
(8) All components (e.g. full body harness, self retractable lanyard, carabiner, snap hook, etc.) connected to this MSA Workman Tripod MUST be compatible. MSA
Workman Tripod is designed to be used with MSA approved components and connecting subsystems. Use of the MSA Workman Tripod subassembly with products
made by others that are not approved in writing by MSA may adversely affect the functional capability between system components and reliability of the complete
system. Contact MSA with any questions or for further information.
(9) Good medical fitness of the user is necessary in order to carry out work at a height. Certain medical conditions can threaten the users' safety during normal use
of MSA Workman Tripod and in emergencies (taking medications, cardiovascular problem, etc.). In any case of doubt, consult your physician before using. Pregnant
women and minors MUST NEVER use the MSA Workman Tripod.
A full body harness certified to EN 361 (TP TC 019/2011, DSTU EN 361:2001) is the only acceptable body holding device that can be used in a fall arrest system.
A fall arrest system, MUST ONLY be connected to the harness back D-ring or front D-ring only with the fall arrest attachment tag "A". These points can also be used
for connecting a rescue system. Never use the hip D-ring for fall arrest or climbing protection. The hip D-ring of a harness MUST ONLY be used for connecting a work
positioning system (EN358, TP TC 019/2011, DSTU EN 361:2001) and NEVER a fall arrest system or climbing protection.
The MSA Workman Tripod MUST be fully inspected before each use to verify that it is in serviceable condition. Examine every inch of the Tripod for severe wear,
missing or broken elements, corrosion, or other damage. Examine if label is missing or illegible; if there is evidence of improper function, improper fit, or alteration of
any component. Do not use MSA Workman Tripod until confirmed in writing by a competent person if inspection reveals an unsafe condition. Additionally, the MSA
Workman Tripod MUST be inspected by a competent person at least annually, or more frequently if subjected to harsh conditions or excessive use. The competent
person must be authorized by current legislation in the country of use. See inspection guidelines.
DO NOT modify or attempt repairs on the MSA Workman Tripod. Only MSA or parties with written authorization from MSA may repair an MSA Workman Tripod. The
system shall not be used outside its limitations, or for any purpose other than that for which it is tended.
Any Tripod which has been subjected to the forces of arresting a fall must be immediately removed from service and marked as "UNUSABLE" until submitted to, and
released from, the formal inspection procedures.
It is essential for the safety of the user that if the MSA Workman Tripod is re-sold outside the original country of destination the reseller shall provide instructions and
additional relevant information for use, for maintenance, for periodic examination and for repair in the language of the country in which the MSA Workman Tripod is to
be used. Failure to follow these warnings or misuse can cause serious personal injuries or death.
Strictly adhere to the cleaning instructions in this section to prevent adverse effects on the materials used in the MSA Workman Tripod. Clean the Tripod with a solution
of water and mild laundry detergent. Dry hardware with a clean cloth. Do not speed dry with heat. Excessive accumulation of dirt, paint or other foreign matter may
prevent proper function of the components, and, in severe cases can weaken them. Questions concerning component conditions and cleaning should be directed to
MSA.
Equipment which is damaged or in need of maintenance must be tagged as "UNUSABLE" and removed from service. Corrective maintenance (other than cleaning)
and repair, such as replacement of elements, must be performed by the MSA factory. Do not attempt field repairs.
Store the MSA Workman Tripod in a cool, dry and clean place out of direct sunlight. Avoid areas where heat, moisture, light, oil, and chemicals or their vapours or
other degrading elements may be present. Equipment which is damaged or in need of maintenance should not be stored in the same area as usable equipment.
Heavily soiled, wet, or otherwise contaminated equipment should be properly maintained (e.g. dried and cleaned) prior to storage. Prior to using equipment which has
been stored for long periods of time, a Formal Inspection should be performed by a competent person. Tripod shall be protected from any mechanical deformation or
mechanical stress (or impact). Typical case – the people just leave it on material stock and put heavy items on it rapidly. Transport the MSA Workman Tripod in a package
to protect it from cuts, moisture, chemicals and their vapours, extreme temperatures, and ultraviolet rays. Dispose in accordance with local regulations.
Page 16
WARNINGS

MAINTENANCE AND STORAGE

ENGLISH
© 2016 MSA
