194
PostBase One (postage meter)
Hand feed tray
Weighing
platform
Static scale
To adjust the display incli-
nation: Press the key
Flap, with print system
below
Ventilation slots
Battery compartment
Display / touch screen (hinged)
Label dispenser
Stylus for touch screen operation
(stored either left or right in a receptacle on the back of the display housing)
Rocker switch (ON / OFF)
CAN BUS
Protective glass
Fleece tray
with ink fleece
Power connection
Letter guide face (black)
9-pin interface
(power sealer connection)
Safety sign
Interfaces:
Serial interface
Interface for connection of
optional components
(e.g. feeder, sealer)
Static scale connection
PC connection
USB port
Ethernet / LAN port (LAN)
Letter catch
tray
