160
PostBase One Mailing System
Insert housing connector
Housing connector
Coupling feeder – sealer – dynamic scale – postage meter
Housing connector
• Place the PostBase One and its optional
Please refer to page 173 for the standing sur-
face values of the system in different config-
urations.
The components of the mailing system are
mechanically coupled and thus fixated with
regard to their position in relation to one
another by means of housing connectors.
• Slightly lift the postage meter on its right
On the dynamic scale and the feeder:
• Insert the connectors in the same way into
• Slightly lift the sealer on its left side, move
• Slightly lift the dynamic scale on its left
• Slightly lift the postage meter on its left
Postage meter
If your mailing system does not comprise all
components mentioned, couple those you
use in the described way.
components on a firm, level, low vibration
horizontal base.
side and slide the connector into the clear-
ance of the housing.
the right side wall.
it close to the feeder and position it on the
connector.
side, move it close to the sealer and posi-
tion it on the connector.
side, move it close to the dynamic scale,
and position it on the connector.
