ANTENNA
Wireless LAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
GPS Interface
STANDARDS
CONNECTOR
ANTENNA
Configuration Interface
INTERFACES
PROTOCOLS
SPEED
CONNECTOR
Power
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
Dimensions and Weight
TYPE
Teldat H2 RAIL Lite
Antennas are supplied separately from the device
802.11n a/b/g 2x2
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b: 1, 2, 5.5, 6, 9, and 11 Mbps
802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, and m0-m15
Up to 2 coaxial connectors, type N
Antennas are supplied separately from the device
SiRFstarIV
RF FME Male
3.3 V Active. These are supplied independently to the device
This can be configured in two modes:
Asynchronous Port :
V24 DCE. Does not permit Hardware flow control.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA
Asynchronous Port:
300 at 115,200 bps
Local console:
9,600 bps (configurable up to 115,200)
DB9 female located on the front panel of the device.
+110 V DC
150 mA @110 V DC
15 W
Ruggedized casing for 19" rack
Technical Information
