GE Multilin 565 Instruction Manual page 97

Location Message Line
S 13.1
SETPOINTS
PHASE CURVES
S 13.2
PHASE CURVE
CHANGE DISABLED
Only message S 13.8 will appear if DISABLED is selected in message S 13.2.
S 13.3
SWITCH TO CURVE2
AFTER RECL. # 1
S 13.4
PH. O/C CURVE 2
SHAPE EXTREM INV
Message S 13.5 will not appear if CUSTOM2 was selected in message S 13.4.
S 13.5
PHASE O/C
TIME DIAL 2
Messages S13.6 and S13.7 will only appear if CUSTOM2 was selected in message S13.4.
S 13.6
TRIP TIME2 (SEC)
L
1.03 xP/U=
A
The remainder of the messages in this section are identical to those found in the PHASE CURRENT page of setpoints.
S 13.7
TRIP TIME2 (SEC)
20.0 xP/U=
L
A
S 13.8
PHASE CURVES
END OF PAGE
Description
The setpoints page 13 header. Setpoints required to program an alternate
phase curve are entered here.
This will enable the changing of the phase curve when enabled.
Enter which reclosure you wish to close onto using the alternative phase
curve. Alternative curves will remain until lockout occurs.
Enter the curve shape for the alternative phase curve.
Enter the time dial for the alternative phase cur ve.
1
The trip time for the first breakpoint of the programmable alternative phase
curve is entered here. The breakpoints are multiples of the pickup current.
1.0
The last trip time is entered here.
1.0
Last line of Setpoints, page 13. Use the PAGE key to view page 14.
SETPOINTS MODE - PHASE CURVES
5-53
