565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP
(DEC) (HEX)
Actual Values - READ ONLY
0531 0213 KVAR DEMAND TIME PERIOD
0532 0214 KVAR DEMAND ALARM
0533 0215 KVAR DEMAND AL'M LEVEL
0534 0216 KVAR DEMAND AL'M RELAY
0535 0217 RESERVED
: : :
0545 0221 RESERVED
0546 0222 MTM METERING MTM COMM. ALARM
0547 0223 MTM COMM. ALARM RELAY
0548 0224 MTM CT SELECT
0549 0225 MTM CT RATING PRIMARY
0550 0226 POWER FACTOR ALARM
0551 0227 P/F LEADING ALARM LEVEL
0552 0228 P/F LAGGING ALARM LEVEL
0553 0229 P/F ALARM DELAY
0554 022A P/F ALARM RELAY
0555 022B POWER FACTOR TRIP
0556 022C P/F LEADING TRIP LEVEL
0557 022D P/F LAGGING TRIP LEVEL
0558 022E P/F TRIP DELAY
0559 022F P/F TRIP RELAY
0560 0230 FREQUENCY ALARM
0561 0231 UNDER FREQ ALARM LEVEL
0562 0232 OVER FREQ. ALARM LEVEL
0563 0233 FREQUENCY ALARM DELAY
0564 0234 FREQUENCY ALARM RELAY
0565 0235 FREQUENCY TRIP
0566 0236 UNDER FREQ. TRIP LEVEL
0567 0237 OVER FREQ. TRIP LEVEL
0568 0238 FREQUENCY TRIP DELAY
0569 0239 FREQUENCY TRIP RELAY
0570 023A MTM SCALING FACTOR
0571 023B VOLTAGE REVERSAL TRIP
0572 023C VOLTAGE REVERSAL DELAY
0573 023D VOLTAGE REVERSAL RELAY
0574 023E RESERVED
: : :
0582 0246 RESERVED
0583 0247 AUTO RECLOSURE AUTO RECLOSURE
0584 0248 (575 Only) NO. OF RECLOSE SHOTS
0585 0249 (575 Only) SHOT 1 DEAD TIME
0586 024A (575 Only) SHOT 2 DEAD TIME
0587 024B (575 Only) SHOT 3 DEAD TIME
0588 024C (575 Only) SHOT 4 DEAD TIME
0589 024D (575 Only) SCHEME RESET TIME
0590 024E (575 Only) RECLOSURE ENABLE RELAY
0591 024F RESERVED
: : :
0599 0257 RESERVED
0600 0258 PHASE CURVES PHASE CURVE CHANGE
0601 0259 (575 Only) SWITCH TO CURVE2 AFTER RECL. #
0602 025A (575 Only) PH. O/C CURVE 2 SHAPE
0603 025B (575 Only) PHASE O/C TIME DIAL 2
0604 025C (575 Only) TRIP TIME2 (SEC) (RESERVED)
0610 0262 GROUND CURVES GROUND CURVE CHANGE
0611 0263 (575 Only) SWITCH TO CURVE2 AFTER RECL. #
0612 0264 (575 Only) GND O/C CURVE 2 SHAPE
0613 0265 (575 Only) GROUND O/C TIME DIAL 2
0614 0266 (575 Only) TRIP TIME2 (SEC) (RESERVED)
0615 0267 SEE SETPOINTS VOLTAGE GROUP
0616 0268 RESERVED
: : :
0999 03E7 RESERVED
1000 03E8 CUSTOM PHASE 1.03 x PU =
1001 03E9 CURVE 1 1.1 x PU =
1002 03EA 1.2 x PU =
1003 03EB 1.3 x PU =
1004 03EC 1.4 x PU =
1005 03ED 1.5 x PU =
1006 03EE 1.6 x PU =
1007 03EF 1.7 x PU =
1008 03F0 1.8 x PU =
DESCRIPTION
6-16
FEATURE INFORMATION
RANGE STEP UNITS SCALE
5 - 120 1 MIN 1.00
0 or 1 - - -
100 - 65000 100 KVAR 1.00
0 - 3 - - -
0 or 1 - - -
0 - 3 - - -
0 or 1 - - -
5 - 5000 5 AMPS 1.00
0 or 1 - - -
0.00 - 1.00 0.05 - 0.01
0.00 - 1.00 0.05 - 0.01
1.0 - 127.0 0.5 SEC 0.10
0 - 3 - - -
0 or 1 - - -
0.00 - 1.00 0.05 - 0.01
0.00 - 1.00 0.05 - 0.01
1.0 - 127.0 0.5 SEC 0.10
0 - 6 - - -
0 or 1 - - -
40.0 - 60.0 0.1 Hz 0.10
50.0 - 72.0 0.1 Hz 0.10
1.0 - 127.0 0.5 SEC 0.10
0 - 3 - - -
0 or 1 - - -
40.0 - 60.0 0.1 Hz 0.10
50.0 - 72.0 0.1 Hz 0.10
1.0 - 127.0 0.5 SEC 0.10
0 - 6 - - -
1 - 655 1 - 1.00
0 or 1 - - -
1.0 - 127.0 0.5 SEC 0.10
0 - 6 - - -
0 or 1 - - -
1 - 4 1 - 1.00
0.3 - 300.0 0.1 SEC 0.10
0.3 - 300.0 0.1 SEC 0.10
0.3 - 300.0 0.1 SEC 0.10
0.3 - 300.0 0.1 SEC 0.10
1 - 255 1 SEC 1.00
0 - 3 - - -
0 or 1 - - -
1 - 4 1 - 1.00
0 - 7 - - -
1 - 32 1 - 1.00
0 or 1 - - -
1 - 4 1 - 1.00
0 - 7 - - -
1 - 32 1 - 1.00
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
0.1 - 1092.2 0.1 SEC 0.10
FORMAT FACTORY
CODE DEFAULT
F14 5
F20 1
F14 1000
F23 0 (565), 2 (575)
F20 1
F23 1 (565), 2 (575)
F41 0
F14 100
F20 1
F14 0.75
F14 0.75
F14 5.0
F23 0 (565), 2 (575)
F20 1
F14 0.70
F14 0.70
F14 1.0
F22 1
F20 1
F14 58.0
F14 62.0
F14 5.0
F23 0 (565), 1 (575)
F20 1
F14 56.0
F14 64.0
F14 1.0
F22 1
F14 655
F20 1
F14 1.0
F22 0
F20 1
F14 4
F14 2.0
F14 4.0
F14 6.0
F14 8.0
F14 5
F23 2
F20 1
F14 1
F21 3
F14 1
F20 1
F14 1
F21 3
F14 1
F14 1.0
F14 1.0
F14 1.0
F14 1.0
F14 1.0
F14 1.0
F14 1.0
F14 1.0
F14 1.0
