ACTUAL VALUES MODE - ANALOG INPUT
Location Message Line
A 2.1
ACTUAL VALUES
ANALOG INPUT
Message A 2.2 will only appear if Analog-In has been disabled in setpoints.
A 2.2
ANALOG INPUT
DISABLED
Message A 2.3 will only appear if Analog In has been enabled in setpoints.
A 2.3
TRANS WNDG TEMP
L
87 DEG C
A
A 2.4
ANALOG INPUT
END OF PAGE
4-4
Description
The actual values page 2 header. The 565/575 Relay can accept an analog
signal from 4 to 20 mA from any device such as a temperature monitor,
and provide trip or alarm signals at a user programmed value. The value of
this temperature, for example, is displayed in this page in whatever units
you select in the setpoints mode. Degrees Celsius are shown.
If Analog-In has been disabled in setpoints, this will be the only message
displayed.
This is the present value of the analog signal being monitored by the Relay,
if this option is used. In this example, the temperature of a transformer
winding is being monitored and degrees Celsius units have been chosen.
Other names and units can be selected, in setpoints mode.
The last line of page 2. Press the PAGE key to view page 3.
