GE Multilin 565 Instruction Manual page 113

565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP
(DEC) (HEX)
Actual Values - READ ONLY
0444 01BC SWITCH NUMBER 4 STATUS
0471 01D7 SWITCH NUMBER 5 STATUS
0472 01D8 SWITCH NUMBER 6 STATUS
0473 01D9 SWITCH NUMBER 7 STATUS
0474 01DA SWITCH NUMBER 8 STATUS
0445 01BD BREAKER OPEN STATUS
0446 01BE BREAKER CLOSED STATUS
0447 01BF ANALOG SELECT A STATUS
0448 01C0 ANALOG SELECT B STATUS
0449 01C1 ANALOG SELECT C STATUS
0450 01C2 ANALOG SELECT D STATUS
0451 01C3 ACCESS JUMPER STATUS
0452 01C4 REMOTE/LOCAL 43 STATUS
0453 01C5 RESERVED
: : :
0454 01C6 RESERVED
0455 01C7 (575 Only) RECLOSE ENABLE STATUS
0456 01C8 (575 Only) RECLOSE DISABLE STATUS
0457 01C9 RESERVED
: : :
0459 01CB RESERVED
0460 01CC LCD DISPLAY CONTRAST
0461 01CD SOFTWARE RELEASE DATE
0463 01CF RESERVED
0464 01D0 FACTORY SERVICE ANALOG OUTPUT FORCED TO
0465 01D1 RESERVED
0466 01D2 TEST LCD DISPLAY? (RESERVED)
0467 01D3 RESERVED
0468 01D4 LOAD FACTORY SETTINGS (RESERVED)
0469 01D5 CAL. ANALOG IN AT 4 mA (RESERVED)
0470 01D6 CAL. ANALOG IN AT 20 mA (RESERVED)
0471 01D7 SEE SETPOINTS CALIBRATION MODE GROUP
: : :
0474 01DA SEE SETPOINTS CALIBRATION MODE GROUP
0475 01DB RESERVED
: : :
0489 01E9 RESERVED
0490 01EA VOLTAGE VT CONNECTION
0491 01EB VT NOMINAL SEC VOLTS
0492 01EC VT PRIMARY VOLTS
0615 0267 ZERO VOLTS DETECT
0493 01ED UNDERVOLT TRIP
0494 01EE UNDERVOLT TRIP LEVEL
0495 01EF UNDERVOLT TRIP DELAY
0496 01F0 UNDERVOLT TRIP RELAY
0497 01F1 UNDERVOLT ALARM
0498 01F2 UNDERVOLT ALARM LEVEL
0499 01F3 UNDERVOLT ALARM DELAY
0500 01F4 UNDERVOLT ALARM RELAY
0501 01F5 OVERVOLT TRIP
0502 01F6 OVERVOLT TRIP LEVEL
0503 01F7 OVERVOLT TRIP DELAY
0504 01F8 OVERVOLT TRIP RELAY
0505 01F9 OVERVOLT ALARM
0506 01FA OVERVOLT ALARM LEVEL
0507 01FB OVERVOLT ALARM DELAY
0508 01FC OVERVOLT ALARM RELAY
0509 01FD RESERVED
: : :
0519 0207 RESERVED
0520 0208 DEMAND METERING AMPS DEMAND
0521 0209 AMPS DEMAND TIME PERIOD
0522 020A AMPS DEMAND ALARM
0523 020B AMP DEMAND ALARM LEVEL
0524 020C AMP DEMAND ALARM RELAY
0525 020D KW DEMAND
0526 020E KW DEMAND TIME PERIOD
0527 020F KW DEMAND ALARM
0528 0210 KW DEMAND ALARM LEVEL
0529 0211 KW DEMAND ALARM RELAY
0530 0212 KVAR DEMAND
DESCRIPTION
6-15
FEATURE INFORMATION
RANGE STEP UNITS SCALE
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 or 1 - -
0 - 10 1 - 1.00
- - -
0 - 255 1 - 1.00
0 - 3 - -
48.0 - 240.0 0.1 VOLTS 0.10
0.10 - 138.00 0.01 kV 0.01
0 or 1 - -
0 or 1 - -
50 - 100 1 %VT 1.00
0.1 - 25.5 0.1 SEC 0.10
0 - 6 - -
0 or 1 - -
50 - 100 1 %VT 1.00
0.1 - 25.5 0.1 SEC 0.10
0 - 3 - -
0 or 1 - -
101 - 125 1 %VT 1.00
0.1 - 25.5 0.1 SEC 0.10
0 - 6 - -
0 or 1 - -
101 - 125 1 %VT 1.00
0.1 - 25.5 0.1 SEC 0.10
0 - 3 - -
0 or 1 - -
5 - 120 1 MIN 1.00
0 or 1 - -
10 - 5000 5 AMPS 1.00
0 - 3 - -
0 or 1 - -
5 - 120 1 MIN 1.00
0 or 1 - -
100 - 65000 100 kW 1.00
0 - 3 - -
0 or 1 - -
FORMAT FACTORY
CODE DEFAULT
- F28 0
- F28 0
- F28 0
- F28 0
- F28 0
- F37 0
- F37 0
- F38 0
- F38 0
- F38 0
- F38 0
- F20 1
- F39 0
- F37 0
- F37 1
F14 5
- F13 Mar 12, 1996
F14 0
- F40 1
F14 120.0
F14 1.20
- F20 1
- F20 1
F14 80
F14 1.0
- F22 3 (565), 1 (575)
- F20 1
F14 85
F14 1.0
- F23 1 (565), 2 (575)
- F20 1
F14 120
F14 1.0
- F22 0 (565), 1 (575)
- F20 1
F14 115
F14 1.0
- F23 0
- F20 0
F14 5
- F20 1
F14 100
- F23 0 (565), 2 (575)
- F20 0
F14 5
- F20 1
F14 1000
- F23 0 (565), 2 (575)
- F20 0
