GE Multilin 565 Instruction Manual page 130

RECORD 01h — 600h
RECORD 02h — 614h
RECORD 03h — 628h
RECORD 04h — 63Ch
RECORD 05h — 650h
RECORD 06h — 664h
RECORD 07h — 678h
RECORD 08h — 68Ch
RECORD 09h — 6A0h
RECORD 0Ah — 6B4h
RECORD 0Bh — 6C8h
RECORD 0Ch — 6DCh
RECORD 0Dh — 6F0h
RECORD 0Eh — 704h
RECORD 0Fh — 718h
RECORD 10h — 72Ch
RECORD 11h — 740h
RECORD 12h — 754h
RECORD 13h — 768h
RECORD 14h — 77Ch
Each of the event records is composed of 40 bytes as shown
below:
DATA BYTE DEFINITION
0-2 Unused
3 Cause of event
4-7 Time of event
8-11 Date of event
12-15 Phase A Current
(If applicable)
16-19 Phase B Current
(If applicable)
20-23 Phase C Current
(If applicable)
24-27 Ground Current
(If applicable)
28-31 Voltage A
(Phase/Line, if applicable)
32-35 Voltage B
(Phase/Line, if applicable)
36-39 Voltage C
(Phase/Line, if applicable)
The phase currents, ground current, and phase voltages are
of a double precision number format which is composed of 1
sign bit, 8 exponential bits, and 23 mantissa bits.
The following lists the possible events and the corresponding
hexadecimal number which will be found at byte 3 of each
event record. Only those events marked with an asterisk will
have their current and voltage parameters recorded.
EVENT NO DESCRIPTION
01h (*) Phase A timed overcurrent trip
02h (*) Phase B timed overcurrent trip
03h (*) Phase C timed overcurrent trip
04h (*) Ground timed overcurrent trip
05h (*) Phase A inst. overcurrent trip
06h (*) Phase B inst. overcurrent trip
07h (*) Phase C inst. overcurrent trip
08h (*) Ground inst. overcurrent trip
09h (*) Phase A hiset instantaneous trip
RECORD 15h — 790h
RECORD 16h — 7A4h
RECORD 17h — 7B8h
RECORD 18h — 7CCh
RECORD 19h — 7E0h
RECORD 1Ah — 7F4h
RECORD 1Bh — 808h
RECORD 1Ch — 81Ch
RECORD 1Dh — 830h
RECORD 1Eh — 844h
RECORD 1Fh — 858h
RECORD 20h — 86Ch
RECORD 21h — 880h
RECORD 22h — 894h
RECORD 23h — 8A8h
RECORD 24h — 8BCh
RECORD 25h — 8D0h
RECORD 26h — 8E4h
RECORD 27h — 8F8h
RECORD 28h — 90Ch
FORMAT
Refer to next table
Binary (-, Second, Minute, Hour)
Binary (-, Day, Month, Year)
Unsigned long integer
Unsigned long integer
Unsigned long integer
Unsigned long integer
Unsigned long integer
Unsigned long integer
Unsigned long integer
APPLICABLE TO
565/575
565/575
565/575
565/575
565
565
565
565
575
FEATURE INFORMATION
EVENT NO DESCRIPTION
0Ah (*) Phase B hiset instantaneous trip
0Bh (*) Phase C hiset instantaneous trip
0Ch (*) Ground hiset instantaneous trip
0Dh (*) Phase A loset instantaneous trip
0Eh (*) Phase B loset instantaneous trip
0Fh (*) Phase C loset instantaneous trip
10h (*) Ground loset instantaneous trip
11h (*) Overvoltage trip
12h (*) Undervoltage trip
13h Analog input trip
14h (*) External trip #1
15h (*) External trip #2
16h (*) External trip #3
17h (*) External trip #4
18h (*) External trip
19h (*) Reclosable trip
1Ah (*) Programmable trip
1Bh Power factor trip
1Ch Frequency trip
1Dh Voltage phase reversal trip
1Eh Phase overcurrent alarm
1Fh Ground overcurrent alarm
20h Overvoltage alarm
21h Undervoltage alarm
22h Analog input alarm
23h Accumulated KA alarm
24h Switch alarm #1
25h Switch alarm #2
26h Amps demand alarm
27h kW demand alarm
28h kvar demand alarm
29h Power factor alarm
2Ah Frequency alarm
2Bh Breaker discrepancy alarm
2Ch Trip coil alarm
2Dh MTM communication alarm
2Eh Phase overcurrent alarm reset
2Fh Ground overcurrent alarm reset
30h Overvoltage alarm reset
31h Undervoltage alarm reset
32h Analog input alarm reset
33h Switch alarm #1 reset
34h Switch alarm #2 reset
35h Breaker alarm reset
36h Access jumper installed
37h Access jumper removed
38h Block instantaneous trip enabled
39h Block instantaneous trip disabled
3Ah Block timed trips enabled
3Bh Block timed trips disabled
3Ch Curve adjust enabled
3Dh Curve adjust disabled
40h Illegal setpoint access
41h System manual reset
42h Reclosure enabled
43h Reclosure disabled
44h Control switch to remote
45h Control switch to local
46h Reclosure #1
47h Reclosure #2
APPLICABLE TO
575
575
575
575
575
575
575
565/575
565/575
565/575
565
565
565
565
575
575
575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
565/575
575
575
565/575
565/575
575
575
6-31
