All the messages displayed by the 565/575 Relay in the
actual values mode are listed and explained in this section.
As already seen, the messages are laid out in book form with
pages containing lines, each of which displays one message.
The 565/575 Relay has two user levels, "basic" and "ad-
vanced". The messages seen depend on this user level,
which is chosen in page one of setpoints. The basic level
allows the user to operate the relay using the minimum of the
features necessary. The advanced level allows the user to
use all the 565/575 Relay features.
The advanced user sees all the messages shown. The
messages which will only be seen by the advanced user and
not the basic user are marked "L
The actual value mode has pages with the following informa-
tion:
Page Contents
1. Current data.
2. Analog Input data.
3. Maintenance data.
4. Operations data.
5. Pretrip data.
6. Voltage and Frequency related data.
7. Event-Recording data.
8. Amps Demand Metering data.
9. MTM Metering data.
The numbers in the "Location" column to the left of each
message in this section give the page and line of that
message in the 565/575 Relay's memory. For example, the
message to the right of A 1.3 in the "Location" column will
appear on page 1 and line 3 when the Relay is in actual
values Mode and is referred to as "message A 1.3". If the
letters "L " appear below a message in this column, this
A
indicates that the message will only appear if the advanced
user level is selected. The message will not appear if the
basic user level is selected.
The "Message Line" column shows the actual message
which can be read from the LCD display on the front panel of
the unit.
Quantities shown in display boxes are typical values only.
Different quantities will be displayed in each particular appli-
cation.
Note: When finished viewing a message, press the LINE
DOWN key to view the next line. When the last line of a page
is reached, press the PAGE key to view the first line of the
next page.
When the last line of the last page in actual values is
reached, pressing the PAGE key will return the display to the
first page again.
", for "Level-advanced".
A
ACTUAL VALUES MODE

Default Message Selection

The default message is the message which will be displayed
by the Relay under normal operating conditions. The display
will show the selected message if no key on the keypad is
pressed for more than four minutes and no alarm or trip
condition is present. Any message in actual values except
page headers, end of page markers, and messages A 3.2, A
3.7, A 4.9, A 7.4, A 7.9, A 7.10, A 8.6, A 8.10 and A 8.14 may
be selected as the default message. The above messages
cannot be used as their function is to allow data to be entered
into the Relay. To select any other message as the default
message, proceed as follows:
Use the PAGE key to select the page on which the required
message is located, in actual values, and use the LINE
DOWN key to display the message. Pressing the STORE key
will cause the following message to be displayed:
NEW DEFAULT
LINE SELECTED
The message selected is now the new default message.

Actual Values Message Abbreviations.

The following abbreviations are used in the actual values
messages:
A Amperes.
AC Access.
BRKR Breaker.
CL'D Cleared.
DEG C Degrees Celsius.
DEM'D Demand.
Hz Hertz.
INS Installed.
INST Instantaneous.
KA Kiloamps.
kVAR Kilovars.
kV Kilovolts.
kW Kilowatts.
MTM Metering Transducer Module.
MWHRS Megawatt Hours.
No. Number.
O/C Overcurrent.
PH Phase.
TEMP Temperature.
TRANS Transformer.
WNDG Winding.
