565/575 DATA FORMATS (REVISION E2.73)
FORMAT APPLICABLE BITS
CODE
F1
16 bits
0000 0000 0001 0010 (BIN) or 0012 (HEX)
0000 0000 0011 1010 (BIN) or 003A (HEX)
F2
16 bits
0000 0000 0000 0000 (BIN) or 0000 (HEX)
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0011 (BIN) or 0003 (HEX)
0000 0000 0000 0100 (BIN) or 0004 (HEX)
0000 0000 0000 0101 (BIN) or 0005 (HEX)
0000 0000 0001 1010 (BIN) or 001A (HEX)
F3 16 bits
0000 XXXX 0000 0000 (BIN) or 0X00 (HEX)
0000 0000 XXXX 0000 (BIN) or 00X0 (HEX)
0000 0000 0000 XXXX (BIN) or 000X (HEX)
0000 0010 0111 0011 (BIN) or 0273 (HEX)
F4 16 bits
0000 0000 0000 0000 (BIN) or 0000 (HEX)
0000 0001 0010 1011 (BIN) or 012B (HEX)
F5 16 bits
0000 0000 XXXX XXXX (BIN) or 00XX (HEX)
XXXX XXXX 0000 0000 (BIN) or XX00 (HEX)
0000 0000 0000 0000 (BIN) or 0000 (HEX)
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0011 (BIN) or 0003 (HEX)
0000 0000 0010 0111 (BIN) or 0027 (HEX)
0000 0001 0000 0000 (BIN) or 0100 (HEX)
0000 0001 0000 0001 (BIN) or 0101 (HEX)
F6 16 bits
0000 0000 0000 0000 (BIN) or 0000 (HEX)
0000 0000 0000 0001 (BIN) or 0001 (HEX)
F7 16 bits
0000 0000 0001 0000 (BIN) or 0010 (HEX)
0000 0000 0010 0000 (BIN) or 0020 (HEX)
F8
16 bits
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0100 (BIN) or 0004 (HEX)
0000 0000 0000 1000 (BIN) or 0008 (HEX)
0000 0000 0001 0000 (BIN) or 0010 (HEX)
0000 0000 0010 0000 (BIN) or 0020 (HEX)
0000 0000 0100 0000 (BIN) or 0040 (HEX)
0000 0000 1000 0000 (BIN) or 0080 (HEX)
F9
16 bits
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0100 (BIN) or 0004 (HEX)
0000 0000 0000 1000 (BIN) or 0008 (HEX)
0000 0000 0001 0000 (BIN) or 0010 (HEX)
0000 0000 0010 0000 (BIN) or 0020 (HEX)
0000 0000 0100 0000 (BIN) or 0040 (HEX)
0000 0000 1000 0000 (BIN) or 0080 (HEX)
F10
16 bits
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0100 (BIN) or 0004 (HEX)
0000 0000 0000 1000 (BIN) or 0008 (HEX)
0000 0000 0001 0000 (BIN) or 0010 (HEX)
0000 0000 0010 0000 (BIN) or 0020 (HEX)
0000 0000 0100 0000 (BIN) or 0040 (HEX)
0000 0000 1000 0000 (BIN) or 0080 (HEX)
F11
16 bits
0000 0000 0000 0001 (BIN) or 0001 (HEX)
0000 0000 0000 0010 (BIN) or 0002 (HEX)
0000 0000 0000 0100 (BIN) or 0004 (HEX)
0000 0000 0000 1000 (BIN) or 0008 (HEX)
MULTILIN PRODUCT DEVICE CODE
18 (DEC) = 565 Feeder Management Relay
58 (DEC) = 575 Feeder Management Relay
565/575 HARDWARE REVISION
00 (DEC) = Undefined
01 (DEC) = A
02 (DEC) = B
03 (DEC) = C
04 (DEC) = D
05 (DEC) = E
: :
26 (DEC) = Z
565/575 FIRMWARE REVISION
Major Revision Digits (0 through 9 only)
Minor Revision Digits (0 through 9 only)
Ultra Minor Revision Digits (0 through 9 only)
Example: Revision 2.73 Stored As 0273 (HEX)
565/575 FIRMWARE MODIFICATION
000 (DEC) = No Modification (Standard Feeder Management Relay)
299 (DEC) = Modification 299
START OF EVENT QUEUE (POINTER TO MOST RECENT EVENT)
Points To Most Recent Event Record Number (0 through 39 only)
Wrap Around Counter Incremented Every 40 Events
000 (DEC) = No. Of Events Register At 74 (HEX) Points To Most Recent Event Record
001 (DEC) = Points To Event Record 01 As The Most Recent Event
002 (DEC) = Points To Event Record 02 As The Most Recent Event
003 (DEC) = Points To Event Record 03 As The Most Recent Event
: :
039 (DEC) = Points To Event Record 39 As The Most Recent Event
256 (DEC) = Points To Event Record 40 As The Most Recent Event
257 (DEC) = Points To Event Record 01 As The Most Recent Event
565/575 TRIP STATUS
0 (DEC) = 565/575 Not Tripped Since Last Reset
1 (DEC) = 565/575 Tripped Since Last Reset
BREAKER POSITION STATUS
16 (DEC) = Breaker Open
32 (DEC) = Breaker Closed
ALARM STATUS I
001 (DEC) = Undefined
002 (DEC) = MTM Communication Alarm
004 (DEC) = Switch Alarm 2
008 (DEC) = Trip Coil Supervision Alarm
016 (DEC) = Frequency Alarm
032 (DEC) = Power Factor Alarm
064 (DEC) = KVAR Demand Alarm
128 (DEC) = KW Demand Alarm
Note: Multiple Alarms Can Be Reported
ALARM STATUS II
001 (DEC) = Amps Demand Alarm
002 (DEC) = Accumulated KA Alarm
004 (DEC) = Overvoltage Alarm
008 (DEC) = Undervoltage Alarm
016 (DEC) = Analog In Alarm
032 (DEC) = Switch Alarm 1
064 (DEC) = Ground Alarm
128 (DEC) = Phase Alarm
Note: Multiple Alarms Can Be Reported
EXTERNAL SWITCH STATUS
001 (DEC) = External Switch 1 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
002 (DEC) = External Switch 2 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
004 (DEC) = External Switch 3 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
008 (DEC) = External Switch 4 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
016 (DEC) = External Switch 5 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
032 (DEC) = External Switch 6 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
064 (DEC) = External Switch 7 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
128 (DEC) = External Switch 8 Active (N/O Switch Is Closed) or (N/C Switch Is Open)
Note: Multiple Switches Can Be Reported
OUTPUT CONTACT STATUS
001 (DEC) = Aux 3 Relay Is Or Has Been Activated By A Trip Since Last Reset (*)
002 (DEC) = Aux 2 Relay Is Or Has Been Activated By A Trip Since Last Reset (*)
004 (DEC) = Aux 1 Relay Is Or Has Been Activated By A Trip Since Last Reset (*)
008 (DEC) = Trip Relay Is Or Has Been Activated By A Trip Since Last Reset (*)
FEATURE INFORMATION
DEFINITION
6-24
