GE Multilin 565 Instruction Manual page 76

SETPOINTS MODE - CONFIGURATION
Location Message Line
OPTION NOT
AVAILABLE
Message S 4.38 will only appear if enable is selected and stored in message S 4.36.
S 4.38
BREAKER DISCREP.
DELAY
S 4.39
TRIP COIL SUPER-
VISION DISABLED
OPTION NOT
AVAILABLE
S 4.40
ACCUMULATED KA
ALARM DISABLED
Messages S 4.40 and 4.41 will only appear if enable is selected and stored in message S 4.39.
S 4.41
ACCUMULATED KA
ALARM
S 4.42
KA ALARM RELAY
S 4.43
EVENT RECORDING:
L
A
OPTION NOT
AVAILABLE
S 4.44
EVENT PRINTING:
L
A
S 4.45
COLD LOAD P/U
L BLOCK
(575)
A
S 4.45
COLD LOAD P/U
DELAY
L
A
5-32
Description
b) The CLOSE relay was activated but the breaker remained open.
A breaker discrepancy causes the reclosure scheme to immediately
lockout.
This message appears if ENABLED is selected in S 4.36 but the 565 does
not have the option card installed.
This setpoint defines the amount of time that the breaker has to clear a
fault. If the 52b contact does not respond after this time, a Breaker
1000 mS
Discrepancy Alarm occurs and Aux 4 output is activated.
This feature allows a small current to flow through the trip coil of the
breaker to ensure it is continuous and the breaker will trip when called to
do so. The function is only active when the breaker is closed. If the current
flow is less than 0.8 mA, the failsafe Aux 3 relay will de-energize.
This message appears if ENABLED is selected in S 4.39 but the 565 does
not have the option card installed.
This message asks if you want the accumulated KA
disabled.
The accumulated KA
100000 in steps of 10. This accumulated value gives an indication of
5000
breaker pole wear and the alarm can be used to indicate when an
inspection should occur.
This message allows the user to select the relay which the alarm signal
generated in message S 4.39 will activate.
AUX1
This message allows the user to enable/disable the built in event recorder.
The event recorder in the 575 will also recognize all events associated with
ENABLED
autoreclosure. These include: trips, reclosures, alarms and lockout.
This message appears if ENABLED is selected in S 4.43 but the 565 does
not have the option card installed.
This message allows users to choose whether to print events as they
occur or not. If ONLINE is selected, each event is printed as it occurs.
OFFLINE
This setpoint allows the user to select whether LOWSET, HIGHSET, or
BOTH types of instantaneous trips should be blocked after a manual
LOSET
breaker close.
The time period after a manual breaker closure for which instantaneous
phase and ground trips will be blocked is entered here. The range is 0 to 10
0.0 SEC
seconds in steps of 0.1 seconds. Entering a value of 0.0 disables this
feature.
2 alarm level is entered here in the range of 5000 to
2 alarm enabled or
