GE Multilin 565 Instruction Manual page 95

Location Message Line
S 12.1
SETPOINTS
AUTO RECLOSURE
S 12.2
AUTO RECLOSURE
DISABLED
S 12.3
NO. OF RECLOSE
SHOTS
S 12.4
SHOT 1 DEAD TIME
2.0 SEC
S 12.5
SHOT 2 DEAD TIME
4.0 SEC
S 12.6
SHOT 3 DEAD TIME
6.0 SEC
S 12.7
SHOT 4 DEAD TIME
8.0 SEC
S 12.8
SCHEME RESET
TIME
S 12.9
RECLOSURE ENABLE
RELAY
Description
The setpoints page 12 header. All the setpoints required for Auto Reclosure
are entered in this page.
This setpoint determines whether the reclosure scheme is enabled or
disabled when LOCAL mode is selected.
selected this setpoint cannot be changed and the flash message
will be displayed.
The setpoints in messages S12.3 to S12.9 can only be stored while
autoreclosure is disabled. If an attempt is made to store a setpoint while
reclosure is enabled, the following message will flash:
Range: DISABLED/ENABLED.
This setpoint determines the number of reclose shots to implement.
Range: 0-4.
4
This setpoint determines the dead time after the first trip. The first
reclosure will be initiated after this time has elapsed.
Range: 0.3-300 sec.
This is part of 79R14 in the Autoreclosure Logic schematic.
Same as above for the second trip.
Range: 0.3-300 sec.
This is part of 79R14 in the Autoreclosure Logic schematic.
Same as above for the third trip.
Range: 0.3-300 sec.
This is part of 79R14 in the Autoreclosure Logic schematic.
Same as above for the four th trip.
Range: 0.3-300 sec.
This is part of 79R14 in the Autoreclosure Logic schematic.
The time required for the reclosure TIME scheme to reset itself. This timer
will not operate unless the phase current in all phases is below the pickup
5 SEC
level.
Range: 1-255, increments of 1.
This is 79TR18, 79TR20, 79TR22, and 79TR24 in the Autoreclosure Logic
schematic.
This setpoint determines which relay will activate when reclosure is
enabled.
AUX2
SETPOINTS MODE - AUTORECLOSURE
ILLEGAL STORE
IN REMOTE MODE
NO STORE WHILE
RECLOSE ENABLE
When REMOTE mode is
5-51
