565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP
(DEC) (HEX)
Actual Values - READ ONLY
0281 0119 TRIP TIME (SEC) (RESERVED)
0282 011A RESERVED
: : :
0299 012B RESERVED
0300 012C GROUND CURRENT GROUND CURRENT SENSING
0301 012D SENSING SYSTEM
0302 012E CT RATIO PRIMARY
0303 012F SEE SETPOINTS GROUND CURRENT GROUP
0304 0130 GROUND TIMED O/C PICKUP
0303 012F GND O/C CURVE SHAPE (565) or GND O/C CURVE 1 SHAPE (575)
0305 0131 GROUND O/C TIME DIAL (565) or GROUND O/C TIME DIAL 1 (575)
0306 0132 GROUND O/C RELAY
0307 0133 GROUND O/C ALARM
0308 0134 GND O/C ALARM LEVEL
0309 0135 GND O/C ALARM DELAY
0310 0136 GND O/C ALARM RELAY
0311 0137 GROUND INST TRIPS (565) or GND HISET INST TRIPS (575)
0312 0138 GND INST TRIP LEVEL (565) or GND HISET INST TRIP LEVEL (575)
0325 0145 GND INST TRIP 2 LEVEL (565) or GND HISET INST TRIP2 LEVEL (575
0313 0139 GND INST TRIP DELAY (565) or GND HISET INST DELAY (575)
0314 013A GND INST TRIP RELAY (565) or GND HISET INST RELAY (575)
0315 013B (575 Only) GND AUTOBLK INST HISET
0316 013C (575 Only) GND AUTOBL HISET AFTER RECL.#
0317 013D (575 Only) GND LOSET INST TRIPS
0318 013E (575 Only) GND LOSET INST TRIP LEVEL
0326 0146 (575 Only) GND LOSET INST TRIP2 LEVEL
0319 013F (575 Only) GND LOSET INST DELAY
0320 0140 (575 Only) GND LOSET INST RELAY
0321 0141 (575 Only) GND AUTOBLK INST LOSET
0322 0142 (575 Only) GND AUTOBL LOSET AFTER RECL.#
0323 0143 TRIP TIME (SEC) (RESERVED)
0324 0144 RESERVED
0325 0145 SEE SETPOINTS GROUND CURRENT GROUP
: : :
0326 0146 SEE SETPOINTS GROUND CURRENT GROUP
0327 0147 RESERVED
: : :
0328 0148 RESERVED
0329 0149 CONFIGURATION SEE SETPOINTS CONFIGURATION GROUP
: : :
0339 0153 SEE SETPOINTS CONFIGURATION GROUP
0340 0154 SET TIME
0342 0156 SET DATE
0344 0158 RESET BLOCKED
0345 0159 BLOCK INST TRIPS
0346 015A BLOCK TIMED O/C TRIPS
0339 0153 BLOCK GND TRIPS
0347 015B DEFINITE TIME # 1 ALARM
0348 015C DEFINITE TIME #1 DELAY
0349 015D DEFINITE TIME #1 RELAY
0373 0175 DEFINITE TIME # 2 ALARM
0374 0176 DEFINITE TIME #2 DELAY
0375 0177 DEFINITE TIME #2 RELAY
0350 015E EXTERNAL TRIP #1 (565) or EXTERNAL TRIP (575)
0351 015F EXTERNAL TRIP #1 RELAY (565) or EXTERNAL TRIP RELAY (575)
0329 0149 (565 Only) EXTERNAL TRIP #1 DELAY
0352 0160 SEE SETPOINTS CONFIGURATION GROUP
: : :
0362 016A SEE SETPOINTS CONFIGURATION GROUP
0363 016B RESERVED
: : :
0364 016C RESERVED
0365 016D SEE SETPOINTS CONFIGURATION GROUP
: : :
0375 0177 SEE SETPOINTS CONFIGURATION GROUP
0376 0178 EXTERNAL TRIP #2 (565) or RECLOSABLE TRIP (575)
0377 0179 EXTERNAL TRIP #2 RELAY (565) or RECLOSABLE TRIP RELAY (575)
0330 014A (565 Only) EXTERNAL TRIP #2 DELAY
0378 017A EXTERNAL TRIP #3 (565) or PROGRAMMABLE TRIP (575)
0379 017B EXTERNAL TRIP #3 RELAY (565) or PROGRAMABLE TRIP RELAY (575)
DESCRIPTION
6-13
FEATURE INFORMATION
RANGE STEP UNITS SCALE
0 or 1 - - -
0 or 1 - - -
10 - 5000 5 AMPS 1.00
5 - 150 1 % CT 1.00
0 - 7 - - -
1 - 32 1 - 1.00
0 - 6 - - -
0 or 1 - - -
0.5 - 3.0 0.1 X P/U 0.10
1 - 255 1 SEC 1.00
0 - 3 - - -
0 or 1 - - -
1.0 - 7.0 0.1 X P/U 0.10
1.0 - 18.0 0.1 X P/U 0.10
0 - 40 1 CYC 1.00
0 - 6 - - -
0 or 1 - - -
1 - 4 1 - 1.00
0 or 1 - - -
1.0 - 7.0 0.1 X P/U 0.10
1.0 - 18.0 0.1 X P/U 0.10
0 - 40 1 CYC 1.00
0 - 2 - - -
0 or 1 - - -
1 - 4 1 - 1.00
- - - -
- - - -
0 - 8 - - -
0 - 8 - - -
0 - 8 - - -
0 - 8 - - -
0 - 8 - - -
1 - 255 1 SEC 1.00
0 - 3 - - -
0 - 8 - - -
1 - 255 1 SEC 1.00
0 - 3 - - -
0 - 8 - - -
0 - 6 - - -
0 - 60 1 CYC 1.00
0 - 8 - - -
0 - 6 - - -
0 - 60 1 CYC 1.00
0 - 8 - - -
0 - 6 - - -
FORMAT FACTORY
CODE DEFAULT
F20 0
F24 0
F14 100
F14 40
F21 3
F14 1
F22 0 (565), 1 (575)
F20 1
F14 1.5
F14 1
F23 0 (565), 1 (575)
F20 0
F14 3.0
F14 3.0
F14 0
F22 0 (565), 1 (575)
F20 1
F14 4
F20 0
F14 3.0
F14 3.0
F14 0
F22 1
F20 1
F14 4
F13 -
F13 -
F26 0
F26 0
F26 0
F26 0
F26 0
F14 1
F23 1 (565), 2 (575)
F26 0
F14 1
F23 1 (565), 2 (575)
F26 0
F22 3 (565), 1 (575)
F14 0
F26 0
F22 3 (565), 1 (575)
F14 0
F26 0
F22 3 (565), 1 (575)
