565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP
(DEC) (HEX)
Actual Values - READ ONLY
0090 005A RESERVED
: : :
0091 005B RESERVED
0040 0028 VOLTAGE VOLTS PHASE A-X
0041 0029 VOLTS PHASE B-X
0042 002A VOLTS PHASE C-X
0043 002B FREQUENCY OF FEEDER
0092 005C SEE ACTUAL VALUES DEMAND & METERING DATA
: : :
0114 0072 SEE ACTUAL VALUES DEMAND & METERING DATA
0115 0073 EVENT RESERVED
0116 0074 NO. OF EVENTS:
0117 0075 VIEW EVENTS? (RESERVED)
0118 0076 RESERVED
0119 0077 PRINT EVENTS? (RESERVED)
0120 0078 CLEAR EVENTS? (RESERVED)
0121 0079 EVENTS CLEARED LAST:
0092 005C DEMAND DATA PH-A PEAK DEMAND
0094 005E PH-B PEAK DEMAND
0096 0060 PH-C PEAK DEMAND
0098 0062 CLEAR AMP DEMAND DATA? (RESERVED)
0099 0063 DATA CLEARED LAST:
0101 0065 PEAK KW DEMAND
0102 0066 CLEAR KW DEMAND DATA? (RESERVED)
0103 0067 KW DEMAND DATA CL'D:
0105 0069 PEAK KVAR DEMAND
0106 006A CLEAR KVAR DEM'D DATA? (RESERVED)
0107 006B KVAR DEMAND DATA CL'D:
0109 006D METERING KW AND KVAR POWER SIGNS
0110 006E DATA POWER FACTOR
0111 006F FREQUENCY MTM
0112 0070 REAL POWER
0113 0071 REACTIVE POWER
0114 0072 REAL ENERGY USED
0123 007B RESERVED
: : :
0255 00FF RESERVED
Setpoints - READ/WRITE
0256 0100 USER LEVEL USER LEVEL
0257 0101 SECURITY FEATURE
0258 0102 SETPOINT ACCESS
0259 0103 RESERVED
0260 0104 PHASE CURRENT PHASE CT RATING PRIMARY
0261 0105 SEE SETPOINTS PHASE CURRENT GROUP
0262 0106 PHASE TIMED O/C PICKUP
0261 0105 PHASE O/C CURVE SHAPE (565) or PH. O/C CURVE 1 SHAPE (575)
0263 0107 PHASE O/C TIME DIAL (565) or PHASE O/C TIME DIAL 1 (575)
0264 0108 PHASE O/C TRIP RELAY
0265 0109 PHASE O/C ALARM
0266 010A PHASE O/C ALARM LEVEL
0267 010B PHASE O/C ALARM DELAY
0268 010C PHASE O/C ALARM RELAY
0269 010D PHASE INST TRIPS (565) or PHASE HISET INST TRIPS (575)
0270 010E PHASE INST TRIP LEVEL (565) or PHASE HISET INST TRIP LEVEL (575
0271 010F PHASE INST TRIP DELAY (565) or PHASE HISET INST DELAY (575)
0272 0110 PHASE INST TRIP RELAY (565) or PHASE HISET INST RELAY (575)
0273 0111 (575 Only) PH AUTOBLK INST HISET
0274 0112 (575 Only) PH AUTOBLK HISET AFTER RECL.#
0275 0113 (575 Only) PHASE LOSET INST TRIPS
0276 0114 (575 Only) PHASE LOSET INST TRIP LEVEL
0277 0115 (575 Only) PHASE LOSET INST DELAY
0278 0116 (575 Only) PHASE LOSET INST RELAY
0279 0117 (575 Only) PH AUTOBLK INST LOSET
0280 0118 (575 Only) PH AUTOBLK LOSET AFTER RECL.#
DESCRIPTION
6-12
FEATURE INFORMATION
RANGE STEP UNITS SCALE
0 TO 431.25 --- KVOLTS 0.01
0 TO 431.25 --- KVOLTS 0.01
0 TO 431.25 --- KVOLTS 0.01
--- --- Hz 0.01
0 TO 40 --- --- 1.00
--- --- --- ---
--- --- AMPS 0.01
--- --- AMPS 0.01
--- --- AMPS 0.01
--- --- --- ---
--- --- KW 1.00
--- --- --- ---
--- --- KVAR 1.00
--- --- --- ---
--- --- --- ---
--- --- --- 0.01
--- --- Hz 0.10
0 T0 +/- 65535 --- KW 1.00
0 T0 +/- 65535 --- KVAR 1.00
--- --- MWHRS 1.00
0 or 1 - -
0 or 1 - -
0 or 1 - -
10 - 5000 5 AMPS 1.00
25 - 250 1 %CT 1.00
0 - 7 - -
1 - 32 1 - 1.00
0 - 6 - -
0 or 1 - -
0.5 - 3.0 0.1 X P/U 0.10
1 - 255 1 SEC 1.00
0 - 3 - -
0 or 1 - -
1.0 -18.0 0.1 X P/U 0.10
0 - 40 1 CYC 1.00
0 - 6 - -
0 or 1 - -
1 - 4 1 - 1.00
0 or 1 - -
1.0 - 18.0 0.1 X P/U 0.10
0 - 40 1 CYC 1.00
0 - 2 - -
0 or 1 - -
1 - 4 1 - 1.00
FORMAT FACTORY
CODE DEFAULT
F14 ---
F14 ---
F14 ---
F14 ---
F14 ---
F13 ---
F12 ---
F12 ---
F12 ---
F13 ---
F14 ---
F13 ---
F14 ---
F13 ---
F16 ---
F17 ---
F14 ---
F18 ---
F18 ---
F14 ---
- F19 1
- F20 1
- F20 0
F14 100
F14 100
- F21 3
F14 1
- F22 0 (565), 1 (575)
- F20 1
F14 1.5
F14 1
- F23 0 (565), 1 (575)
- F20 0
F14 3.0
F14 0
- F22 0 (565), 1 (575)
- F20 1
F14 4
- F20 0
F14 2.0
F14 0
- F22 1
- F20 1
F14 4
