GE Multilin 565 Instruction Manual page 75

Location Message Line
CONDITION
NO TRIP
TRIPPED
(Current > Trip Level)
TRIPPED
(Current < Trip Level)
KEYPAD RESET
CONDITION
NO ALARM
ALARM
(Current > Alarm Level)
ALARM
(Current < Alarm Level)
KEYPAD RESET
Message S4.34 will only appear if pulsed operation is assigned to the Aux 2 relay.
S 4.35
AUX2 RELAY PULSE
TIME
CONDITION
NO ALARM
ALARM
(Open Trip Coil)
ALARM
(Closed Trip Coil)
KEYPAD RESET
S 4.36
BREAKER RESPONSE
DELAY
S 4.37
BREAKER DISCREP.
DISABLED
(565)
Description
OUTPUT AUX. 1
RELAY
DE-ENERGIZED
ENERGIZED
DE-ENERGIZED
DE-ENERGIZED
OUTPUT AUX. 1
RELAY
DE-ENERGIZED
ENERGIZED
DE-ENERGIZED
DE-ENERGIZED
This message allows the user to set the length of the pulse for the Aux 2
relay when selected for pulse operation. The pulse time controls the
0.6 SEC
minimum length of time that the relay will be energized. The range of
values for this setpoint is 0.1 to 0.6 seconds in steps of 0.1 seconds.
Note: The Auxiliary 3 relay is failsafe and designed to operate in an
OUTPUT
AUX. 3 RELAY
ENERGIZED
DE-ENERGIZED
ENERGIZED
ENERGIZED
This setpoint allows the user to enter the actual delay between the time
when the trip contact closure is sent to the breaker and the opening of the
1 mS
breaker contacts. After the time delay specified, the 565/575 will begin to
accumulate the KA
quantity from the breaker manufacturer's data of breaker opening time.
The range of values which may be entered is 1 to 167 mS.
This message asks if you want the Breaker Discrepancy Alarm ENABLED
or DISABLED (Aux4). This feature monitors the 52a and 52b breaker
auxiliary contact and gives an alarm indication in two possible situations:
a) The TRIP relay was activated but the breaker remained closed.
SETPOINTS MODE - CONFIGURATION
FACEPLATE
AUX. 1 LED
OFF
ON
FLASHING
OFF
FACEPLATE
AUX. 1 LED
OFF
ON
OFF
OFF
unlatched mode only. It is not programmable.
FACEPLATE
AUX. 3 LED
OFF
ON
OFF
OFF
2
value of the breaker interruption. Determine this
MODBUS READ EXCEPTION
STATUS
00H
22H
02H
00H
MODBUS READ EXCEPTION
STATUS
00H
20H
00H
00H
MODBUS READ EXCEPTION
STATUS
00H
10H
00H
00H
5-31
