Location Message Line
A 5.1
ACTUAL VALUES
PRE-TRIP DATA
A 5.2
ALARM: PHASE O/C
ALARM: GROUND
O/C
ALARM: OVERVOLT
ALARM: UNDERVOLT
ALARM: ANALOG
INPUT
ALARM:
ACCUMULATED KA
SWITCH ALARM 1
ALARM: AMPS
DEMAND
ALARM: KW DEMAND
ALARM: KVAR
DEMAND
ALARM: POWER
FACTOR
ALARM: FREQUENCY
ALARM: BREAKER
DISCREPANCY
ACTUAL VALUES MODE - PRE-TRIP DATA
Description
The actual values page 5 header. This page displays the cause of the
current alarm and the cause of the last trip. It also gives data on the
condition of the feeder when a trip was last initiated by the 565/575 Relay.
This page can be viewed immediately after an alarm or trip to determine its
cause. Also, if an overcurrent trip has occurred, then the phase currents
can be inspected to check which phase or phases caused this.
This message will only appear if the condition causing the alarm is present.
In this case the current in any or all of the phases is exceeding the phase
alarm limit set up in setpoints mode.
This message indicates that the present alarm is caused by the ground
current exceeding the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the voltage
sensed between phases or between a phase and the neutral line rose
above the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the voltage
sensed between phases or between a phase and the neutral line dropped
below the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the analog
input exceeding the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the Accumu-
lated KA exceeding the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the external
switch programmed to create a Definite Time alarm.
This message indicates that the present alarm is caused by the Amps
Demand exceeding the limits specified in setpoints mode.
This message indicates that the present alarm is caused by the kW
Demand exceeding the limits specified in setpoints mode. ** 565 requires
Option Card **
This message indicates that the present alarm is caused by the kVAR
Demand exceeding the limits specified in setpoints mode. ** 565 requires
Option Card **
This message indicates that the present alarm is caused by the MTM
Power Factor exceeding the limits specified in setpoints mode. ** 565
requires Option Card **
This message indicates that the present alarm is caused by the MTM
Frequency exceeding the limits specified in setpoints mode. ** 565 re-
quires Option Card **
This message indicates that the present alarm is caused by the feeder
breaker not responding within the time limit specified in setpoints mode.
