Actual Values - GE Multilin 565 Instruction Manual

Location Message Line
A 1.1

ACTUAL VALUES

CURRENT
A 1.2
PHASE A CURRENT
710 A
A 1.3
PHASE B CURRENT
715 A
A 1.4
PHASE C CURRENT
710 A
Message A 1.5 will only appear if Ground Sensing has been enabled in setpoints.
A 1.5
GROUND CURRENT
A 1.6
PHASES
B= 715
PHASES
B<2% CT
A 1.7
CURRENT
END OF PAGE
Description
The actual values page 1 header. This page gives information on the
feeder phase and ground currents being monitored by the 565 Relay.
This is the actual monitored RMS current flowing in phase A of the feeder.
This is the actual monitored RMS current flowing in phase B of the feeder..
This is the actual monitored RMS current flowing in phase C of the feeder.
This is the actual leakage current flowing to ground in the system.
10 A
This message allows all three phase currents to be displayed if they are
A= 710
greater than 2% CT.
C= 710
When the breaker is closed and the current is less than 2% of CT, the three
A<2% CT
phase display will reflect this with "<2% CT".
C<2% CT
The last line of page 1, actual values. Press the PAGE key to view page 2.
ACTUAL VALUES MODE - CURRENT
4-3
