GE Multilin 565 Instruction Manual page 83

Location Message Line
S 8.1
SETPOINTS
CALIBRATION MODE
S 8.2
EXERCISE RELAY
Before testing, verify that it is safe to do so. (These tests can only be done with the feeder breaker open.) If the breaker
is closed, the following flash message will be displayed:
BREAKER MUST
BE OPEN
S 8.3
PRESS STORE
TO END TEST...
S 8.4
PRESS RESET TO
RESET RELAY
S 8.5
SWITCH NUMBER 1
L
A
STATUS
S 8.6
L
BREAKER OPEN
A
STATUS
S 8.7
BREAKER CLOSED
L
A
STATUS
S 8.8
ANALOG SELECT A
L
A STATUS
S 8.9
ACCESS JUMPER
L L
A A
STATUS
S 8.10
REMOTE/LOCAL 43
L
A
STATUS
S 8.11
L
RECLOSE ENABLED
A
STATUS
Description
The setpoints page 8 header. This page is used to test the operation of the
565 switch inputs and output relays. As well, the LCD display contrast can
be adjusted on this page.
This message is used to test the operation of the output relay contacts.
The following choices are available:
TRIP
1) Trip.
2) Aux. 1.
3) Aux. 2.
Select the required relay using the NEXT CHOICE key. Press the store key
to simulate the presence of a condition that will activate the selected relay.
This message appears while the activating condition is present. The relay
will be tested in the mode of operation assigned to it. For example, a
latched relay will be energized and will then remain latched. Press the
STORE key to remove the simulated activating condition.
This message appears on the display for two seconds to remind the user
that if a latched relay has been tested, then the reset key must now be
pressed to return the relay to its inactive state.
This message allows each of the external switches to have its status
checked. Use the LINE DOWN key to display each of the switches. The
OPEN
status of each switch, either OPEN or CLOSED will appear in the mes-
sage.
This message allows the breaker open external contacts to have their
status checked.
YES
This message allows the breaker closed external contacts to have their
status checked.
NO
This message allows each of the analog select switches to have its status
checked. Use the LINE DOWN key to display each of the switches. The
OFF
status of each switch, either ON or OFF, will appear in the messages.
This message indicates the status of the access jumper. ENABLED
indicates jumper installed. DISABLED indicates jumper not installed.
ENABLED
LOCAL
This message indicates the status of the internal hardware relay which
enables or disables the reclosing scheme.
YES
SETPOINTS MODE - CALIBRATION
4) Aux. 3.
5) Aux. 4 (575 only)
6) Block Tap Changer (575 only)
7) ALL
5-39
