FEATURE INFORMATION
Cause of Event
1) Phase A Timed O/C Trip
2) Phase B Timed O/C Trip
3) Phase C Timed O/C Trip
4) Ground Timed O/C Trip
5) Phase A Inst Trip
6) Phase B Inst Trip
7) Phase C Inst Trip
8) Ground Inst Trip
9) Overvoltage Trip
10) Undervoltage Trip
11) Analog Input Trip
12) External Trip #1
13) External Trip #2
14) External Trip #3
15) External Trip #4
16) Power Factor Trip
17) Frequency Trip
18) Phase O/C Alarm
19) Ground O/C Alarm
20) Overvoltage Alarm
21) Undervoltage Alarm
22) Analog Input Alarm
23) Accumulated KA2 Alarm
24) Definite Time Alarm 1
25) Definite Time Alarm 2
26) Amps Demand Alarm
27) KW Demand Alarm
28) KVAR Demand Alarm
29) Power Factor Alarm
30) Frequency Alarm
31) Breaker Discepancy Alarm
32) Trip Coil Alarm
33) MTM Communications Alarm
34) Phase O/C Alarm Reset
35) Ground O/C Alarm Reset
36) Overvoltage Alarm Reset
37) Undervoltage Alarm Reset
38) Analog Input Alarm Reset
39) Definite Time Alarm1 Reset
40) Definite Time Alarm2 Reset
41) Breaker Discrepancy Alarm Reset
42) Access Jumper Installed
43) Access Jumper Removed
44) Block Inst Trip Enabled
45) Block Inst Trip Disabled
46) Block Timed O/C Trips Enabled
47) Block Timed O/C Trips Disabled
48) Curve Adjust Enabled
49) Curve Adjust Disabled
50) Illegal Setpoint Access
51) System Manual Reset
52) Control Switch to Remote
53) Control Switch to Local
6-2
Displayed Message
PH-A TIME O/C T
PH-B TIME O/C T
PH-C TIME O/C T
GND TIMED O/C T
PH-A INST O/C T
PH-B INST O/C T
PH-C INST O/C T
GND INST O/C T
OVERVOLTAGE T
UNDERVOLTAGE T
ANALOG INPUT T
EXT. TRIP #1 T
EXT. TRIP #2 T
EXT. TRIP #3 T
EXT. TRIP #4 T
P/F TRIP T
FREQ. TRIP T
PH O/C ALARM A
GND O/C ALARM A
OVERVOLTAGE A
UNDERVOLTAGE A
ANALOG INPUT A
ACCUM KA A
SWITCH ALARM1 A
SWITCH ALARM2 A
AMPS DEMAND A
KW DEMAND A
KVAR DEMAND A
P/F ALARM A
FREQ. ALARM A
BRK DISCRPNCY A
TRIP COIL A
MTM COMM ALM A
PH OC ALM RST O
GD OC ALM RST O
OV ALARM RST O
UV ALARM RST O
AI ALARM RST O
SW ALM1 RST O
SW ALM2 RST O
BRK ALM RST O
AC JUMPER INS O
AC JUMPER REM O
INST-BLOCK EN O
INST-BLOCK DI O
TIMED-BLK ENB O
TIMED-BLK DIS O
CURVE ADJ. EN O
CURVE ADJ. DI O
ILL-ACCESS O
MANUAL RESET O
SWITCH REMOTE O
SWITCH LOCAL O
