Location Message Line
CONDITION
NO TRIP
TRIPPED
(Current > Trip Level)
TRIPPED
(Current < Trip Level)
KEYPAD RESET
CONDITION
NO ALARM
ALARM
(Current > Alarm Level)
ALARM
(Current < Alarm Level)
KEYPAD RESET
Message S4.32 will only appear if pulsed operation is assigned to the Aux 1 relay.
S 4.32
AUX1 RELAY PULSE
TIME
(565)
Message S4.33 will only appear if pulsed operation is assigned to the Aux . 2 relay.
S 4.33
AUX2 RELAY PULSE
TIME
(575)
S 4.34
AUX 2 RELAY
UNLATCHED
Description
OUTPUT AUX. 1
RELAY
DE-ENERGIZED
ENERGIZED
DE-ENERGIZED
DE-ENERGIZED
OUTPUT AUX. 1
RELAY
DE-ENERGIZED
ENERGIZED
DE-ENERGIZED
DE-ENERGIZED
This message allows the user to set the length of the pulse for the Aux 1
relay when selected for pulse operation. The pulse time controls the
0.6 SEC
minimum length of time that the relay will be energized. The range of
values for this setpoint is 0.1 to 0.6 seconds in steps of 0.1 seconds.
As with the Aux. 1 relay, this message allows the user to set the length of
the pulse for the Aux. 2 relay.
0.6 SEC
This setpoint allows the user to select the mode of operation for the Aux 2
relay. The available modes are pulsed, latched or unlatched. The Aux 2
relay does not look at the 52a/52b contacts. If the Aux 2 relay is
programmed as pulsed, only alarm conditions should be assigned to
it.
Pulsed Operation
If pulsed operation is selected and a fault condition develops, the Aux 2
relay is energized and de-energized repeatedly. The rate at which the Aux
2 relay toggles is determined by the Aux 2 relay pulse timer setpoint S 4.34.
Only when the fault current drops below pick up will Aux 2 relay stop
pulsating.
SETPOINTS MODE - CONFIGURATION
FACEPLATE
AUX. 1 LED
OFF
ON
FLASHING
OFF
FACEPLATE
AUX. 1 LED
OFF
ON
OFF
OFF
MODBUS READ EXCEPTION
STATUS
00H
44H
04H
00H
MODBUS READ EXCEPTION
STATUS
00H
40H
00H
00H
