Appendix B: GPIB Interface Specification

Interface Functions
AWG710 Arbitrary Waveform Generator Programmer Manual
This appendix lists and describes the GPIB functions and messages the
waveform generator implements.
Table B–1 lists the GPIB interface functions this instrument implements. Each
function is briefly described on the next page.
Table B-1: GPIB interface function implementation
Interface function
Acceptor Handshake (AH)
Source Handshake (SH)
Talker (T)
Listener (L)
Service Request (SR)
Remote/Local (RL)
Parallel Poll (PP)
Device Clear (DC)
Device Trigger (DT)
Controller (C)
Electrical Interface
Implemented
subset
Capability
AH1 Complete
SH1 Complete
T6 Basic Talker, Serial Poll
Unaddress if my listen address (MLA)
No Talk Only mode
L4 Basic Listener
Unaddress if my talk address (MTA)
No Listen Only mode
SR1 Complete
RL1 Complete
PP0 None
DC1 Complete
DT1 Complete
C0 None
E2 Three state driver
B-1
