Tektronix AWG710 Programmer's Manual page 41

Gateway Mnemonics
Marker Mnemonics
Remote Device
Mnemonics
Source to Output
Connections
AWG710
AWG710 Arbitrary Waveform Generator Programmer Manual
These commands specify the gateway to use as a mnemonic in the header.
Symbol
GATeway1
GATeway2
GATeway3
These commands specify the marker to use as a mnemonic in the header.
Symbol
MARKer1
MARKer2
These commands specify the remote device to use as a mnemonic in the header.
Symbol
RDEVice1
RDEVice2
RDEVice3
The following illustrations shows the source to output connections for the
AWG710 instruments.
Channel1 SOURce1
Waveform
Meaning
Gateway 1
Gateway 2
Gateway 3
Meaning
The signal for the marker 1
The signal for the marker 2
Meaning
Network drive 1
Network drive 2
Network drive 3
OUTPut1
Dout1 (Except option02)
Command Syntax
2-11
