AWG710 Arbitrary Waveform Generator Programmer Manual
Table 3-14: Device errors (Cont.)
Error code Error message
6150 CH1 Waveform memory chip data bus failure
6151 to 6186 CH1 Waveform memory chip data bus bit0 to bit35
6200 CH1 Waveform memory address bus failure
6201 to 6219 CH1 Waveform memory address bus bit0 to bit18
6300 CH1 Waveform memory chip cell failure
6301 to 6336 CH1 Waveform memory chip 0 to chip 35
6350 CH1 Waveform memory chip select failure
6351 to 6386 CH1 Waveform memory chip select 0 to select 35
7000 Output failure
7100 Internal offset failure
7101 CH1 internal offset
7104 CH1 internal offset
7200 Output offset failure
7201 CH1 output offset
7204 CH1 output offset
7300 Arb gain failure
7301 CH1 Arb gain
7304 CH1 Arb gain
7400 Direct gain failure
7401 CH1 Direct gain
7404 CH1 Direct gain
7510 5dB 1 attenuator failure
7511 CH1 1 5dB attenuator
7514 CH1 1 5dB attenuator
7520 5dB 2 attenuator failure
7521 CH1 5dB 2 attenuator
7524 CH1 5dB 2 attenuator
7530 10dB attenuator failure
7531 CH1 10dB attenuator
7534 CH1 10dB attenuator
7540 20dB attenuator failure
7541 CH1 20dB attenuator
7544 CH1 20dB attenuator
7610 20MHz filter failure
7611 CH1 20MHz filter
7614 CH1 20MHz filter
7620 50MHz filter failure
Messages and Codes
3-25
