Status Byte Register
(SBR)
AWG710 Arbitrary Waveform Generator Programmer Manual
The SBR is made up of 8 bits. Bits 4, 5 and 6 are defined in accordance with
IEEE Std 488.2-1987 (see Figure 3–2 and Table 3–1). These bits are used to
monitor the output queue, SESR, and service requests, respectively. The contents
of this register are returned when the *STB? query is used.
6
RQS
7
5
4
3
ESB MAV
OSS
QSS
6
MSS
Figure 3-2: The Status Byte Register (SBR)
Table 3-1: SBR bit functions
Bit
Function
7
Operation Summary Status (OSS).
6
RQS (Request Service)/MSS (Master Summary Status). When the instrument
is accessed using the GPIB serial poll command, this bit is called the Request
Service (RQS) bit and indicates to the controller that a service request has
occurred (in other words, that the GPIB bus SRQ line is LOW). The RQS bit is
cleared when serial poll ends.
When the instrument is accessed using the *STB? query, this bit is called the
Master Summary Status (MSS) bit and indicates that the instrument has issued
a service request for one or more reasons. The MSS bit is never cleared to 0 by
the *STB? query.
5
Event Status Bit (ESB). This bit indicates whether or not a new event has
occurred after the previous Standard Event Status Register (SESR) has been
cleared or after an event readout has been performed.
4
Message Available Bit (MAV). This bit indicates that a message has been
placed in the output queue and can be retrieved.
3
Questionable Summary Status (QSS).
2
Event Queue Available (EAV).
1-0
Not used
2
1
0
EAV
Status and Event Reporting
3-5
