4.20 Register Descriptions – MCU Control
4.20.1 DEVID0 – Device ID register 0
4.20.2 DEVID1 – Device ID register 1
4.20.3 DEVID2 – Device ID register 2
4.20.4 REVID – Revision ID
8331B–AVR–03/12
DEVID0, DEVID1 and DEVID2 contain the byte identification that identifies each microcontroller
device type. For details on the actual ID, refer to the device datasheet.
Bit 7
+0x00
Read/Write R
Initial Value 0
• Bit 7:0 – DEVID0[7:0]: Device ID Byte 0
Byte 0 of the device ID. This byte will always be read as 0x1E. This indicates that the device is
manufactured by Atmel.
Bit 7
+0x01
Read/Write R
Initial Value 1/0
• Bit 7:0 – DEVID[7:0]: Device ID Byte 1
Byte 1 of the device ID indicates the flash size of the device.
Bit 7
+0x02
Read/Write R
Initial Value 1/0
• Bit 7:0 – DEVID2[7:0]: Device ID Byte 2
Byte 2 of the device ID indicates the device number.
Bit 7
+0x03 –
Read/Write R
Initial Value 0
• Bit 7:4 – Reserved
These bits are unused and reserved for future use.
6 5 4
DEVID0[7:0]
R R R
0 0 1
6 5 4
DEVID1[7:0]
R R R
1/0 1/0 1/0
6 5 4
DEVID2[7:0]
R R R
1/0 1/0 1/0
6 5 4
– – –
R R R
0 0 0
Atmel AVR XMEGA AU
3 2 1
R R R
1 1 1
3 2 1
R R R
1/0 1/0 1/0
3 2 1
R R R
1/0 1/0 1/0
3 2 1
REVID[3:0]
R R R
1/0 1/0 1/0
0
DEVID0
R
0
0
DEVID1
R
1/0
0
DEVID2
R
1/0
0
REVID
R
1/0
47
