28.17.7 SCAN – Channel Scan register
8331B–AVR–03/12
• Bit 3:0 – Reserved
These bits are unused and reserved for future use. For compatibility with future devices, always
write these bits to zero when this register is written.
Scan is enabled when COUNT is set differently than 0. This register is available only for ADC
channel 0.
Bit 7
+0x06
Read/Write R/W
Initial Value 0
• Bit 7:4 – OFFSET[3:0]: Positive MUX Setting Offset
The channel scan is enabled when COUNT != 0 and this register contains the offset for the next
input source to be converted on ADC channel 0 (CH0). The actual MUX setting for positive input
equals MUXPOS + OFFSET. The value is incremented after each conversion until it reaches the
maximum value given by COUNT. When OFFSET is equal to COUNT, OFFSET will be cleared
on the next conversion.
• Bit 3:0 – COUNT[3:0]: Number of Input Channels Included in Scan
This register gives the number of input sources included in the channel scan. The number of
input sources included is COUNT + 1. The input channels included are the range from
MUXPOS + OFFSET to MUXPOS + OFFSET + COUNT.
6 5 4
OFFSET[3:0]
R/W R/W R/W
0 0 0
Atmel AVR XMEGA AU
3 2 1
COUNT[3:0]
R/W R/W R/W
0 0 0
0
SCAN
R/W
0
