A.3.1. STANDARD AND SEMI-MICRO CUVETTES
(Several brands available)
A.3.2. ULTRA-MICRO CUVETTES (HELLMA)
When ordering, specify the Z-dimension to be 15 mm.
Hellma Cat. No.
1.Hellma: http://www.hellma-worldwide.com.
SpectraMax M2 & SpectraMax M2e Multi-mode Plate Readers User Guide — 0112-0102 Rev. D
A.3. Cuvettes in SpectraMax M2 and SpectraMax M2
1
Internal Width Minimum Volume
10 mm
4 mm
2 mm
Window Size
105.201-QS 2.0 x 5.0 mm
a 2.0 x 2.5 mm
105.202-QS
0.8 mm diameter
b
105.210-QS
a.You must put a riser (0.8–1 mm) on cuvette bottom to match the cuvette window to the beam.
b.You must put a riser (0.8–1 mm) on cuvette bottom to match the cuvette window to the beam.
Gives good qualitative results (i.e. spectral scans), but quantitative results are impractical because
the window is smaller than the beam.
Maximum Volume
~ 1.8 mL 4.0 mL
~ 0.75 mL 1.4 mL
~ 0.40 mL 0.7 mL
Chamber Volume
100 µL
50 µL
5 µL
e
Fill Volume
120 µL
70 µL
10 µL
