4.1.

CUVETTE READ: QUICK OVERVIEW

If you are an experienced user of this instrument, the following steps provide a quick
reminder of the basic operating procedures required to read a cuvette using a SpectraMax
M2 or SpectraMax M2
Turn on the power switch (located on the back panel). The microplate drawer opens
1
automatically.
If you want to regulate the temperature inside the chamber, touch the
2
(incubator) key to turn the incubator on and bring the chamber to the default temper-
ature of 37.0°C. The microplate drawer closes.
If the incubator is on, the LCD shows the current temperature along with the temper-
3
ature set point. To change the set point (to any setting from ambient +4° to 45°C),
press the up or down arrow keys.
Select desired measurement wavelength by pressing the up or down arrow near λ .
4
Load the prepared cuvette into the chamber, being sure that the clear sides are left and
5
right (when facing the instrument).
Press the
6
4.2.

MICROPLATE READ: QUICK OVERVIEW

If you are an experienced user of this instrument, the following steps provide a quick
reminder of the basic operating procedures required to read a microplate using a
SpectraMax M2 or SpectraMax M2
Turn on the power switch (located on the back panel). The microplate drawer opens
1
automatically.
If you want to regulate the temperature inside the chamber, touch the
2
(incubator) key to turn the incubator on and bring the chamber to the default temper-
ature of 37.0°C. The microplate drawer closes.
If the incubator is on, the LCD shows the current temperature along with the temper-
3
ature set point. To change the set point (to any setting from ambient +4° to 45°C),
press the up or down arrow keys.
SpectraMax M2 & SpectraMax M2e Multi-mode Plate Readers User Guide — 0112-0102 Rev. D
e
:
or key.
REF READ CUVETTE
e
:

4. Operation

TEMP on/off
TEMP on/off
25
