Creating A Route Policy For Rip - Cisco ASR 9000 Series Configuration Manual

Implementing RIP

Creating a Route Policy for RIP

This task defines a route policy and shows how to attach it to an instance of a RIP process. Route policies can
be used to:
• Control routes sent and received
• Control which routes are redistributed
• Control origination of the default route
A route policy definition consists of the route-policy command and name argument followed by a sequence
of optional policy statements, and then closes with the end-policy command.
A route policy is not useful until it is applied to routes of a routing protocol.
SUMMARY STEPS
1. configure
2. route-policy name
3. set rip-metric number
4. end-policy
5. commit
6. configure
7. router rip
8. route-policy route-policy-name { in | out }
9. commit
DETAILED STEPS
Command or Action
Step 1
configure
Step 2
route-policy name
Example:
RP/0/RSP0/CPU0:router(config)# route-policy IN-IPv4
Step 3 set rip-metric number
Example:
RP/0/RSP0/CPU0:router(config-rpl)# set rip metric
42
Step 4
end-policy
Example:
RP/0/RSP0/CPU0:router(config-rpl)# end-policy
OL-30423-03
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.1.x
Creating a Route Policy for RIP
Purpose
Defines a route policy and enters route-policy
configuration mode.
(Optional) Sets the RIP metric attribute.
Ends the definition of a route policy and exits
route-policy configuration mode.
455
