19. Regenerate brake resistor selection guide
Model (Motor Wattage)
400W
550W-1KW
1.5KW-2KW
3KW
4.5KW
6KW
8.6KW
11KW
15KW
22KW
30KW
Resistance (Ohm)
100
100
60
60
30
30
15
10
5
5
2.5
The resistance can be parallel or series to get a closed value.
Power Rating
80
80
150
150
300
300
600
800
1500
1500
3000
67
