1. Checking Mokon series products on delivery

Follow the procedure below to check Mokon Series products upon delivery
Check the following items when Mokon Series products are delivered:
1. Check the packed products for damages that may have occurred during shipping.
2. Check whether the name and number of the delivered products are the same as those on the
delivery sheet.
3. Check whether the servomotor and servo drive capacity and encoder specification are the same
as the ordered.
4. In the case of special order, please carefully check the delivered products and contact our
company immediately if any item is incorrect.
The table below shows the standard set:
1. One servomotor
2. One servo drive
3. One 37PIN D type connector for CN1*
4. One 15PIN D type connector for CN2*
5. One connector for servomotor power line*
6. One encoder connector*
7. One copy of wiring description
* If cable is your option, they will be soldered ready with the cable.
1.1 Servomotor nameplate descriptions
Servo drive Model
Rated Output
Motor Rated Speed
Serial Number
5
Encoder Specification
