15
SPECIFICATIONS

■ IC-U82

GENERAL
• Frequency coverage
USA
Europe, Korea
General (LM), China
* 1 Guaranteed: 440–450 MHz range only.
* Guaranteed: 430–440 MHz range only.
2
• Type of emission
• Number of memory channels : 207 (incl. 6 scan edges and 1 call)
• Frequency resolution
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability
• Power supply requirement
• Current drain
(at 7.2 V DC: approx.)
Transmit
Receive
• Antenna connector
• Dimensions
(proj. not included)
• Weight (approx.)
All stated specifications are subject to change without notice or obligation.
72
: (unit: MHz)
Tx: 420–450* /Rx: 400–479*
1 1
Tx/Rx: 430–440
Tx/Rx: 400–479*
2
: FM
: 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
: ±2.5 ppm
(–10°C to +60°C)
: 7.2 V DC (6–10.3 V DC acceptable;
Icom's battery pack only)
:
at 5 W (High) 2.0 A
at 2 W (Middle) 1.4 A
at 0.5 W (Low) 0.9 A
standby 80 mA
power save 30 mA
max. audio 250 mA
: BNC
(50 Ω)
: 54(W) × 139(H) × 36.7(D) mm
1 15 7
2 ⁄ (W)×5 ⁄ (H)×1 ⁄ (D) in
8 32 16
: 390 g; 13.8 oz
(with BP-222N and Ant.)
200 g; 7.1 oz
(without battery pack and Ant.)
TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power (at 7.2 V) : 5 W/2 W/0.5 W (High/Mid/Low)
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dBc
• Microphone connector : 3-conductor 2.5 (d) mm (
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.35 MHz, 2nd: 450 kHz
• Sensitivity : 0.16 µV typical
(at 12 dB SINAD)
• Squelch sensitivity : 0.11 µV typical
(threshold)
• Selectivity :
[Wide]
[Narrow]
• Spurious and image rejection : 70 dB typical
• Intermodulation : 65 dB typical
• AF output power : More than 0.3 W
(at 7.2 V DC)
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
• Ext. data connector : 3-conductor 2.5 (d) mm (
/±2.5 kHz
[Wide] [Narrow]
1
⁄ ")/2.2 kΩ
8
More than 55 dB
More than 50 dB
at 10% distortion with
an 8 Ω load
1
⁄ ")/8 Ω
8
1
⁄ ")
8
