Solid State Logic Matrix Owner's Manual page 81

Chapter 5 - DAW Control
The Edit Menu
MarkIn and MkOut mark In and Out edit points during playback. In>Out sends the keyboard short cut to play between the In and
Out marks.
The remaining five functions are the standard Pro Tools Edit commands (Seper is the Separate function).
The Misc Menu
Auto displays the current track automation mode in the upper row of the scribble strip, replacing the track names.
Mon displays the track Input Monitor mode in the upper row of the scribble strip, replacing the track names.
Group displays the track Group Status in the upper row of the scribble strip, replacing the track names with the Group ID letter.
A lowercase letter indicates the channel is a member of one group; an uppercase letter indicates the channel is a member of
multiple groups, with the topmost group ID displayed.
SEL
Create opens the New Group Dialogue on screen. Select the tracks to be grouped via the DAW keys prior to using the
Create function. Then press the ENTER key in the Transport/Utility area of the centre section to accept the default group
name and ID. Alternatively enter a new name/ID via a standard USB keyboard.
Suspnd temporarily suspends all Mix groups. Pressing this switch again returns to the previous Group status. When Suspnd is
enabled, the switch tally flashes.
ClrPk is the HUI F1 function key and clears the Matrix and on-screen meter clip indicators.
Fixed is the HUI F5 function key and toggles the V-Pot encoders between Fixed and Velocity sensitive modes when they are used
to control a plug-in. Default mode is Velocity sensitive.
Status brings the Session Setup menu on Screen.
Transport/Utility Keys
All the standard HUI utility and additional transport functions are assigned to their respective front panel keys. PREVIOUS,
NEXT and LAST CUE are SSL derived function keys that are used to recall Pro Tools memory locations, and are described on
Page 69.
Matrix Owner's Manual
73
