6 6 - - 4 4 1 1 H H J J Y Y L L C C 3 3 C C h h a a n n n n e e l l L L C C D D R R e e p p l l a a c c e e m m e e n n t t
•
Follow instruction #4 for 629502XA removal to reveal the display.
•
Remove the three pan Pozi screws and remove the assembly.
•
Fit new assembly and screw in place.
•
Reassemble and test for correct operation.
7 7 - - 4 4 1 1 H H J J Y Y L L C C 3 3 C C e e n n t t r r e e S S e e c c t t i i o o n n L L C C D D R R e e p p l l a a c c e e m m e e n n t t
•
Follow instruction #4 for 629506XA removal to reveal the display.
•
Remove the three pan Pozi screws and remove the assembly.
•
Fit new assembly and screw in place.
•
Reassemble and test for correct operation.
Appendix G - Service
Matrix Owner's Manual
125
