Appendix G - Service
1 1 2 2 - - 6 6 2 2 9 9 5 5 0 0 1 1 X X 2 2 C C h h a a n n n n e e l l M M o o d d u u l l e e R R e e p p l l a a c c e e m m e e n n t t
• Remove the knob caps and retaining collars from the channel module to be replaced.
• Follow instructions #1 and #2 for the removal of the base plate and rear panel.
• Follow the instruction #11 for the removal of 629510X1 channel buscard.
• The faulty module will be attached to the buscard, fit the replacement assembly to the buscard and reassemble.
