D D e e f f a a u u l l t t P P r r o o f f i i l l e e S S o o f f t t K K e e y y A A s s s s i i g g n n m m e e n n t t s s
Soft Key Overview
In the main control section of the console is a two row LCD display with 8 switches above and below. All of these 16 'Soft Keys'
can be programmed to send either DAW specific MIDI commands or keyboard shortcuts. The top row can also be programmed to act as
'Menu' keys for the lower row of switches, Up to 5 sets of Soft Keys can be stored with each Profile. The default Profile for each protocol
includes a suggested set of keys for the top, or Default, set. The remaining four sets are empty. The assignments for the default layer is described
below for each of the default Profiles.
Chapter 6 describes how to customise the Soft Key assignments to suit your own needs.
P P r r o o T T o o o o l l s s D D e e f f a a u u l l t t P P r r o o f f i i l l e e
Main Soft Key Page
The top row of the main soft keys page contains 5 menu selections to access additional commands: V-Pot modes (V-Pot),
Automation Enable (AutoEn), I/O assignment (I/O), Editing (Edit) and a set of miscellaneous functions (Misc). The additional keys
are HUI commands, with the exception of LnkT/E which is the keyboard short cut to enable/disable the Link Edit/Timeline
function. The HUI functions are EdTools which cycles the through the various Pro Tools Edit tools, and EdMode which toggles
between the four Edit modes: Shuffle, Spot, Slip and Grid.
The lower row of the main soft key page contains eight HUI functions:
Edit, Mix, Trans, MemLoc and Plugin are window switches, which control Pro Tools on-screen displays:
- Edit and Mix bring the named window to the foreground.
- Trans opens or closes the Transport window.
- MemLoc opens or closes the Memory Locations window.
- PlugIn opens or closes the floating window for the currently selected plug-in.
Dfault in conjunction with the channel DAW
AutoS activates the Suspend Automation function.
RecRdy is a multifunction key which flashes if any tracks have been Record enabled. Operating the key will then cancel the Record
Enable function on all armed tracks. If no tracks are currently armed, the RecRdy key will record enable all tracks in the session.
SEL
or V-Sel switch, returns the faders and V-Pots to their default settings.
