Chapter 3 - Analogue Signal Flow
T T R R S S o o f f t t K K e e y y s s
The T T R R soft keys allow Matrix's Total Recall functions to be controlled from the console:
Total Recall is described on Page 53.
E E n n a a b b l l e e enables TR for restoring snapshots.
T T a a k k e e T T R R takes a TR snapshot.
S S e e t t S S e e l l sets a TR snapshot to any channels selected using the upper
S S e e t t A A l l l l sets a TR to the whole console.
C C u u r r : : displays the TR number which is currently selected in the
I I P P S S o o f f t t K K e e y y s s
The I I P P soft keys allow you to switch the console's IP address between F F i i x x e e d d and D D H H C C P P .
The IP address information is shown after the D D H H C C P P button. By default, Matrix uses a fixed IP address of 192.168.1.2. with the
subnet mask set to 255.255.255.0.
See Page 5 for a description of how to change the fixed IP address.
See Page 4 for details of configuring the console's Ethernet connectivity.
M M i i s s c c S S o o f f t t K K e e y y s s
The M M i i s s c c soft keys cover miscellaneous Matrix settings:
I I n n p p C C u u configures the channel
any pre-fader feeds from the channel unaffected. Pressing I I n n p p C C u u causes the
muting any feeds from the channel that are not sourced from the INPUT.
O O p p t t D D A A C C switches between the two digital inputs. By default, the AES (XLR) input is selected. Pressing the O O p p t t D D A A C C button
selects the S/PDIF input, and the button lights to indicate that this input has been selected.
Fader Options:
M M s s t t + + 1 1 0 0 rescales the master fader. By default, the master fader reaches 0dB at the top, following the scaling labelled on the
left of the fader. Pressing M M s s t t + + 1 1 0 0 switches the meter's scaling to reach +10dB at the top, following the labelling on the right
of the fader.
0 0 d d B B and O O f f f f move the analogue faders on any channels selected using the upper
Meter Signal Scale Option:
The default scale for all of the LED meters is meters is 0dBfs corresponds to an analogue level of +24dBu. The + + 1 1 8 8 d d B B button
provides an alternative scaling of +18dBu.
USB Keyboard Identifier:
The K K e e y y b b I I D D key is used to identify the nationality of keyboard being emulated by the Matrix USB soft keys. See Page 86 for
details.
Matrix Owner's Manual
44
CUT buttons. By default, pressing the channel
SEL
key.
Total Recall tab of the Matrix Remote.
CUT button mutes the channel output, leaving
CUT buttons to mute the channel after the input,
SEL key to 0dB and -∞ ∞ respectively.
