MINIPCI
LAN
SWITCH
HW ENCRYPTION

1.2 Connections

Caution
Before connecting the router, please read the following instructions carefully.
Workplace Conditions. Main Characteristics
• Excessive cold and heat should be avoided, as should humidity and dust.
• Direct exposure to sunlight should be avoided as well as other heat sources. The device should not be placed
amongst papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed very close to strong electromagnetic fields such as speakers, engines, etc.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
Warning
The electric current in power cables, telephone lines and communication cables is dangerous. To pre-
vent electric shocks, before installing, handling or opening the equipment covers, connect and discon-
nect the cables as follows:
To Connect
Make sure that the device's power supply switch is in the
OFF position
Connect all data cables
Connect the power supply to the device
Turn the power supply switch to the ON position

1.2.1 Power Source Connection

The ATLAS X60 router is powered with an internal power source.
To avoid electric shocks, residual current circulation and other unwanted effects, also affecting communications, the
following is recommended:
Warning
All interconnected communication devices should be plugged to THE SAME GROUNDED POWER
OUTLET, which should at the same time be of good quality (lower than 10 ohms).
Whether the workplace is provided with an uninterrupted power supply system (UPS), regulated supply
or it is independent from the rest (such as lighting, etc.); it is highly recommended that all data devices
should be connected to the same power source. This will avoid operating and premature aging prob-
lems of drivers and other components.
ATLAS X60
1
2 GE
NO
YES
1
2 GE
NO
YES
To Disconnect
Turn the switch OFF
Disconnect the power supply from the device
Disconnect the data cables
1 Installing the Router
1
2 GE
16 (optional)
YES
3
