1 Installing the Router

1.6 16 Port SWITCH Board

"SWC" SLOT for the ATLAS 360 16 port Switch board
Fig. 18:
The ATLAS 360 features and interfaces can be amplified by inserting a 16 port Switch board in the "SWC" slot which
can be found on the device rear panel. In order to correctly insert the board, please follow the steps given below.
(1) Switch off the device and remove the data cables (as described in the section on connection in this manual).
(2) Using a screwdriver, remove the cover over the "SWC" spot. This cover is located on the rear panel.
(3) Should there be a "dummy" board installed, remove it.
(4) Insert the 16 port switch board. This operation must be carefully carried out without forcing any piece or part of
the device.
(5) Screw down the board. Firmly tighten the screws without damaging the board.
(6) Connect and switch on the device as explained in the connection section. Should you detect any problems,
switch off the device and make sure that the above steps have been carried out correctly. If the problem per-
sists, please contact your usual supplier.
(7) Connect a terminal to the console and check that the device detects the Switch board.
**************************************************
******************* Router Teldat ****************
**************************************************
BIOS CODE DUMP...................
BIOS DATA DUMP....
End of BIOS dump
Boot-stack used: 0x000007A0
Boot-stack free: 0x00001860
===========================================================
BIOS TELDAT
===========================================================
FLASH BIOS CODE VERSION: 01.04
Current date: Jan 10 2008, Thursday Current time: 18:09:50
System Info:
PCB:0x083 GPPORCR:0x0BFFFFFF PVR:0x80210020 SVR:0x80390020
CLKs(KHz): CPU=983040 DDR=196608 LBUS=49152 PCI1=65536 PCI2=65536
Watchdog: Disabled
MMU Mode: Dynamic
ICache: ON; DCache: ON Write-Back; L2Cache: ON
Mem Info:
DRAM size: 256 Megabytes
BANK 0: 256 Megabytes (detected)
FLASH: 64 Mb.
NVRAM: 128 Kb.
EEPROM: 2048 Bytes.
Devices:
GIGABIT ETHERNET 1
GIGABIT ETHERNET 2
SWITCH 10/100
SECURITY ENGINE
