Table 4 Cables
Cables
cab-ThinMini-ITX-SATA-Power
cab-ThinMini-ITX-UART
cab-ThinMini-ITX-USB2.0-Single
cab-ThinMini-ITX-USB2.0-Twin
cab-ThinMini-ITX-LVDS-Open End
cab-ThinMini-ITX-BKLT
cab-DP to HDMI Passive
cab-ThinMini-ITX-LVDS
cab-ThinMini-ITX-SATA-Power (50cm lenght)
cab-ThinMini-ITX-SATA-Power (30cm length)
SATA III cable (straight/straight)
SATA III cable (straight/right-angled)
Table 5 Adapters
Adapters
conga-Thin MITX/eDP to DP adapter
conga-Thin MITX/eDP to HDMI adapter
conga-Thin MITX/LVDS Adapter
conga-Thin MITX/Debug Card
conga-DP2VGA
Table 6 Power Supply
PSUs
NB Power Supply (65W, 19V@3.42A)
NB Power Supply (90W, 19V@4.74A)
Copyright © 2017 congatec AG
Part No. Description
14000120 Power cable for SATA and micro-SATA devices.
14000121 UART cable with 2 x 5-pin female housing and D-Sub male connector.
14000122 USB 2.0 cable with 1 x 5-pin female housing and USB 2.0 Type A female connector.
14000123 USB 2.0 cable with twin USB 2.0 Type A female connector and 2x5-pin housing.
14000125 ACES 40 pin-LVDS cable with open end.
14000127 CHYAO SHIUNN 8-pin backlight cable with open end.
14000128
14000129 ACES 50204-40 LVDS cable for Thin Mini-ITX.
14000135 50 cm SATA power cable with 2 x 15-pin female connectors.
14000136 30 cm SATA power cable with 2 x 15-pin female connectors.
48000029 30 cm SATA III data cable with straight connectors at both ends
48000030 30 cm SATA III data cable with straight/right-angled connectors
Part No. Description
052231 eDP to standard DP evaluation adapter
052232 eDP to standard HDMI evalutiona adapter
052233 LVDS pin header evaluation adapter for congatec Thin Mini-ITX boards
047858 Evaluation debug card with post code display, buttons, status LED's and other useful IO's
011132 DP/eDP to VGA adapter
Part No. Description
10000145 FSP065-REBN2, Plug 7.4 x 5.1 x 12.5 mm
10000146 FSP090-DIEBN2, Plug 7.4 x 5.1 x 12.5 mm
ICKLm02 12/59
