2.3 Electric Installation
This subsection describes how to connect the
Area Network (LAN) and how to connect supply voltage and other electric interfaces.
The device must be part of the electrical system of the building.
Device and PCB Connectors
Figures below show the layout of the
Kit
Lite connectors and terminals.
2N TELEKOMUNIKACE a.s., www.2n.cz
®
2N
Helios IP Audio Kit
®
2N
Helios IP Audio Kit
Version R394-1
Version R345v2
into your Local
®
and
2N
Helios IP Audio
23/49
