2N Helios IP Audio Kit Installation Manual page 26

OUTPUTS OUT1+,
OUT1−
OUT2+,
OUT2−
INPUTs IN1+,
IN1−
IN2+,
IN2−
AUDIO MIC+,
MIC−
IN+, IN−
OUT+,
OUT−
SPEAKER SPK+,
SPK−
2N TELEKOMUNIKACE a.s., www.2n.cz
2 programmable active outputs ( supply from PoE: 10 V DC; suply from
external source: voltage minus 2 V, max. 11 V DC ) output current: Max.
600 mA, not available at Lite version
2 programmable galvanically isolated inputs, not available at Lite
version
Microphone input
line input, not available at Lite version
line output, not available at Lite version
Power amplifier output for loudspeaker
26/49
