Mounting Types
Refer to the table below for a list of mounting types and necessary components. Make
sure that the installation site is not exposed to flowing or condensed water.
Wall mounting
Use the proper wall mounting screws and dowels (not included in the delivery). Hang
the device on the wall using the cover bottom holes.
DIN rail mounting
Mount the device to a standard TS 35 DIN rail. The recommended minimum DIN rail
length is 14 cm.
2N TELEKOMUNIKACE a.s., www.2n.cz
21/49
