Poe Supply - 2N Helios IP Audio Kit Installation Manual

PoE Supply

®
2N Helios IP Audio Kit
W) and can be supplied directly from the LAN via compatible network elements. If
your LAN lacks such compatible elements, you can insert a PoE injector, Part No.
91758100E, between your
®
Connect your 2N
successfully.
Caution
In case you feed your
power external power supply, monitor the power consumption of the
whole system. With regard to the PoE 802.3af capacities and efficiency
of the switched-mode power supplies in the device, the maximum
possible device input is approximately 12 W. An overload of the PoE
source usually results in PoE disconnection and, subsequently,
®
2N Helios IP Audio Kit
The 2N
inactive, no load switched on LED1–3 and OUT1–2 outputs) is up to 2 W.
The maximum power amplifier consumption is determined by the
current loudspeaker volume level and impedance (up to 10 W for a 4 Ω
loudspeaker). The real consumption is typically lower and depends on
the characteristics of the signal to be amplified.
If you intend to connect a considerable load to the OUT1 and OUT2
outputs, make sure that the total input does not exceed the above
mentioned limit (12 W for PoE). If the PoE supply fails to provide
sufficient power for the specific application, use a more powerful
external source to make your device work perfectly.
2N TELEKOMUNIKACE a.s., www.2n.cz
is compatible with the PoE 802.3af technology (Class 0–12.95
®
2N Helios IP Audio Kit
Helios IP Audio Kit
®
2N
restart.
®
Helios IP Audio Kit
and the nearest network element.
to the LAN via the LAN1 interface to supply it
Helios IP Audio Kit
consumption at relax (power amplifier
via PoE or from a limited-
28/49
