Connection to Digital Inputs
®
2N
Helios IP Audio Kit
is equipped with two digital inputs on the IN1± and IN2±
terminals. The digital inputs recognise the following two logic levels: log. 0 for voltage
under 1.1 V a log. 1 for voltage over 3 V. Keep the voltage polarity to make the function
work properly. The function is programmable for either input.
2N TELEKOMUNIKACE a.s., www.2n.cz
33/49
