  • Page 1 ® Helios IP Safety Emergency IP Intercom Installation Manual Version www.2n.cz  ...
  • Page 2 The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All development, production and distribution processes of the company are managed by this standard and guarantee a high quality, technical level and professional aspect of all our products.

  • Page 3: Table Of Contents

    Content 1. Product Overview ........4 1.1 Components and Associated Products  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6  ...

  • Page 4: Product Overview

    ® Helios IP Safety can be equipped with a numerical keypad to be used as a code lock for lock switch activating or telephone/subscriber number dialling. ®...

  • Page 5: Advantages Of Use

    Helios IP Safety can also be provided with RFID card reader modules. ® Helios IP Safety is very easy to install. All you have to do is connect the system into your LAN via a network cable and feed it from a 12 V power supply or your PoE supporting LAN.

  • Page 6: Components And Associated Products

    Part No. 9152101W 1 button, 10 W loudspeaker, IP69K ® Helios IP Safety is designed for outdoor applications and requires no additional roof. W-including Part Nos. are intended for WAP pressure cleaning and extremely noisy environments (such as highways, etc.). ®...

  • Page 7: Mounting Accessories

    Part No. 91378354 Grandstream GXV3140 VoIP video telephone Grandstream GXV3175 VoIP telephone Electric Locks Part No. 932070E Part No. 932080E Part No. 932090E BEFO 1211 12 V / 600 BEFO 1221with BEFO 1211MBwith mechanical momentum pin blocking ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 8: Power Supply

    Ethernet PoE injector (PoE) power supply is not available. Additional Modules Part No. Part No. 9151010 Part No. 9137410E Additional switch with normally open/closed contact 9159010 External IP and 12 V switched output. Security Relay relay ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 9: Terms And Symbols

    Warning Always abide by this information to prevent damage to the device. Caution Important information for system functionality. Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 10: Description And Installation

    2. Description and Installation Here is what you can find in this section: 2.1 Before You Start 2.2 Mechanical Installation 2.3 Electric Installation 2.4 Extending Module Connection ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 11: Before You Start

    2.1 Before You Start Product Completeness Check ® Before you start please check the contents of your Helios IP Safety delivery: ® 1× 2N Helios IP Safety 1× Torx 10 / Torx 20 double-ended wrench 1× spare sealing for big bushing for a thick cable, one hole 1×...

  • Page 12: Mechanical Installation

    Hole: (112 × 220 × 70) mm (without flush mounting box) Flush mounting – thermally insulated wall What You Need: Longer screws (depending on the thermal insulation thickness) Hole: (112 × 220 × 70) mm ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 13 Flush mounting – plasterboard wall What You Need: Plasterboard flush mounting box, Part No. 9151002 Hole: (118 × 235) mm Wall mounting (concrete and steel structures, entry barrier columns, etc.) What You Need: ® Just your Helios IP Safety unit ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 14: Common Mounting Principles

    Remember that dowels of poor quality may easily get loose and fall out of the wall! ® Stainless steel screws are used for the Helios IP Safety assembly. Other screws than stainless steel ones corrode soon and may aesthetically deteriorate the surrounding environment!
  • Page 15 We recommend to seal the frame – wall gap with a silicone or another sealant to avoid wall dampening as a result of water leakage. Do not complete mounting until you have finished electrical installation – refer to Mounting Completion ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 16 Suppose that all the required cables have been carried into the drilled hole. Now follow the instructions applicable for classic brick flush mounting. However, remember that thermally insulated walls show less strength than classic brick walls. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 17 Flush Mounting – Hollow Bricks ® Suppose you intend to install your Helios IP Safety unit into a wall made of hollow bricks. Note that the external side of the bricks gets damaged by cutting and the dowels cannot practically be fixed into the thin internal part of the bricks.

  • Page 18: Wall Mounting

    Eliminate the risk of accident! Wall mounting is not suitable for narrow passages or places where people's attention may be distracted. The manufacturer shall not be liable for injuries incurred as a result of unsafe mounting! ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 19: Use Of Cable Bushings

    ® Select the 2N Helios IP Safety position with respect to the supply cables. Where the cables are installed inside a structure or wall, use the hole at the intercom bottom. Drill holes of the depth of 70 mm for dowels in the wall as shown in the figure.
  • Page 20 2. Remove the sealing including the cover from the bushing. Cut either of the components as shown in the figures. 3. Put the bushing nut on the cable and insert the sealing. 4. Replace the cover onto the sealing. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 21 5. Pull the cable connector though the bushing body into the intercom and clip it into the motherboard connector. 6. Move the sealing including the cover along the cable as far as the bushing body, or add a plug if necessary. 7. Replace and tighten the nut. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 22 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 23: Electric Installation

    2.3 Electric Installation ® This subsection describes how to connect Helios IP Safety into your Local Area Network (LAN) and how to connect supply voltage and the electric lock. PCB Connectors ® Picture shows the lay-out of connectors on the...
  • Page 24 ® Figure: 2N Helios IP Safety Connectors, PCB Version 555v3 Description of Connectors: X1 – Loudspeaker X4 – Camera module X5 – Button 1 SW1 – Reset button (555v3 version only) X6 – Configuration jumpers X8 – Extending module (RFID card reader or additional switch) X10 –...

  • Page 25: External Power Supply

    Auto-MDIX function and so both the straight and crossed cable versions can be used. External Power Supply Connection ® Helios IP Safety can be fed either from an external 12 V / 1 A DC power supply or from the LAN equipped with the PoE 802.3af supporting network elements. External Power Supply An external 12 V power supply is connected to terminal block X19.

  • Page 26: Mounting Completion

    Water leakage may damage the electronic part of the system. ® Stainless steel screws are used for the Helios IP Safety assembly. Other screws than stainless steel ones corrode soon and may aesthetically deteriorate the surrounding environment! ®...

  • Page 27: Extending Module Connection

    Additional Switch (Part No. 9151010) is used for extending the number of ® outputs. This extending module is intended for mounting into the 2N Helios IP Safety main unit and is compatible with the basic units with Part No. 915210xxxxx.
  • Page 28 Module settings: ® Refer to the Helios IP Configuration Manual for details. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 29: Specifications

    Helios IP Security Relay is a device installed between an intercom (outside ® the secured area) and the electric lock (inside the secured area). The 2N Helios IP Security Relay includes a relay that can only be activated if the valid opening code is...
  • Page 30 Activate the intercom switch using the keypad, telephone, etc. The first code sent from the intercom will be stored in the memory and considered valid. After code ® initialisation, the Helios IP Security Relay will pass into the operational mode (the green LED is blinking). ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 31 Connection: ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 32: Function And Use

    3. Function and Use ® In this section we describe the basic and extending functions of the 2N Helios IP Safety product. Here is what you can find in this section: 3.1 Configuration 3.2 Maintenance ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 33: Configuration

    3.1 Configuration ® Use a PC equipped with any web browser to configure Helios IP Safety Launch your web browser (Internet Explorer, Firefox, etc.). Enter the IP address of your intercom (http://192.168.1.100/, e.g.). Log in using the Admin user name and password.
  • Page 34 Wait for the second sound signal Press the quick dial button 5 times. ® Helios IP Safety will read its IP address. If the address is 0.0.0.0, it means that the intercom has not obtained the IP address from the DHCP server.
  • Page 35 The 15 times 1 sequence must be entered within 30 seconds after the first sound signal for security reasons. The inter-digit delay may be 2 s at most. The static IP address mode will be switched into the dynamic IP address mode and vice versa upon restart. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 36: Maintenance

    3.2 Maintenance Cleaning ® If used frequently, Helios IP Safety gets dirty. To clean it, use a piece of soft cloth moistened with clean water. We recommend you to obey the following principles while cleaning: Never use aggressive detergents (such as abrasives or strong disinfectants).

  • Page 37: Technical Parameters

    Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC Active switch output: 9 up to 13 V DC depending on power supply (PoE: 9 V; adaptor: power supply voltage minus 1 V), max 700 mA ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 38 Storing temperature: − 40 °C to 70 °C Dimensions 217 × 109 × 83 mm × × 83 mm incl. frame Weight: netto max. 2 kg / brutto max. 2,5 kg Covering level: IP65 , IP69K (91521xxxW) ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 39: Supplementary Information

    5. Supplementary Information Here is what you can find in this section: 5.1 Troubleshooting 5.2 Directives, Laws and Regulations 5.3 General Instructions and Cautions ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 40: Troubleshooting

    5.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 41: Directives, Laws And Regulations

    5.2 Directives, Laws and Regulations Europe ® Helios IP Safety conforms to the following directives and regulations: Directive 1999/5/EC of the European Parliament and of the Council, of 9 March 1999 – on radio equipment and telecommunications terminal equipment and the mutual...
  • Page 42 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 43: General Instructions And Cautions

    The manufacturer also assumes no responsibility for additional costs incurred by the consumer as a result of making calls using a line with an increased tariff. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 44: Electric Waste And Used Battery Pack Handling

    Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 45 2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Phone: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz EN1788_v2.0.1 ® TELEKOMUNIKACE a.s., www.2n.cz...
